Application of
Disassembly
3 - 7
Main motor unit
Application o
f
Disassembly
Application of
Disassembly
1
Disassembly of Motor 3P supply assy
1.
Remove the retaining ring E3 to remove the frange
and motor T-pulley from the shaft of motor 3P
supply assy.
Motor 3P supply assy
Retaining ring E3
Frange
Shaft
Motor T-pulley
64
66
