Brother LS-1817 - Shuttle Driver and Race Way Clearance

- 3 -
Clearance between the shuttle driver and the race way
Standard
•
The shuttle driver should rotate smoothly, no play should be felt in the race way.
Adjustment
1. Loosen setscrews  of the driver shaft gear .
2. Adjust the clearance of the driver shaft .
3. Retighten the setscrews .
