Brother LS-2020 Parts Reference List

- 4 -
(2) UPPER SHAFT AND NEEDLE BAR
No.
CODE NAME REMARKS
No.
CODE NAME REMARKS
1 XE3692001 UPPER SHAFT SUPPLY ASSY 1000006160 New Spec
2 XA0637120 CLUTCH PLATE 41 XD1220131 NEEDLE BAR ASSY N 1000001718
3 XA0636020 CLUTCH SPRING 42 XC3015031 PRESSER FEED HOLDER ASSY 1000001718
4 XA0638120 TIMING PULLEY
5 048080346 RETAINING RING E8 1000001452
6 012500532 SET SCREW SOCKET (FT) M5X5 1000010653
7 014400432 SET SCREW SOCKET (CP) M4X4
8 X52478021 BUSHING PRESSER
9 X57908021 TAPTITE, BIND S M4X10 CHG
10 XA0639021 BALANCE WHEEL
11 XA2358121 NEEDLE BAR (LS-1717, 1817) DEL
12 XA0642120 NEEDLE BAR THREAD GUIDE DEL
(LS-1717, 1817)
13 XA0643121 NEEDLE CLAMP (LS-1717, 1817) DEL
14 XC8563031 NEEDLE CLAMP SCREW 1000002936
XA0644021 NEEDLE CLAMP SCREW (LS-1717, 1817) DEL
15 012400432 SET SCREW SOCKET (FT) M4X4
16 XA8983021 NEEDLE BAR SUPPORTER
17 XA3477021 NEEDLE BAR SUPPORTER STUD 1000002222
18 X54369021 SPRING
19 X56851021 LOCK NUT
20 XE3167001 NEEDLE BAR SUPPORTER GUIDE 1000003433
21 XA1289121 NEEDLE BAR CRANK ROD ASSY
22 XA1113221 NEEDLE BAR CRANK 1000001814
23 132051022 SCREW, FLAT SM3.57-40X7 L
24 XA3954121 ZIGZAG NEEDLE PLATE 1000011532
25 X50487021 SCREW M4 1000010447
26 X57908021 TAPTITE, BIND S M4X10 CHG
27 XA1112121 THREAD TAKE-UP ASSY CHG
28 XA0648120 THREAD TAKE-UP LEVER STUD 050091
29 048050346 RETAINING RING E5 1000001452
30 X57913021 TAPTITE, BIND S M4X16
31 128437020 PRESSER BAR 040158
32 X55770021 PRESSER BAR SPRING 1000001718
33 XA0975021 PRESSER BAR GUIDE BRACKET
34 X52760021 SET SCREW, PAN M6X12
35 XA2511121 PRESSER FOOT LIFTER 1000001718
36 XA0977150 PRESSER FOOT LIFTER STUD
37 138135122 ZIGZAG PRESSER FOOT 1000001718
38 132730122 TIGHTENING SCREW 3.57 CHG
39 XA1866021 WASHER, SPRING 050209
40 X53330020 WASHER 1000003111
