Brother LS-2020 Parts Reference List

- 6 -
(3) FEED MECHANISM
No.
CODE NAME REMARKS
No.
CODE NAME REMARKS
1 XA0978021 FEED CONNECTING ROD ASSY 44 XA9976021 REVERSE SEWING BUTTON (OTHER)
2 XA0980021 SPRING XE2219001 REVERSE SEWING BUTTON 1000001718
3 XA0982020 HORIZONTAL FEED SHAFT (LS-30, X-3)
4 XA0983121 HORIZONTAL FEED ARM ASSEMBLY 45 XA9977021 FEED DIAL CAM
5 021400205 NUT 2 M4 46 X50532021 PRESSER PLATE
6 060401416 SCREW BIND M4X14 47
138172021
SCREW, PAN (S/P WASHER) M4X10 1000017555
7 X53330020 WASHER CHG
8 048050346 RETAINING RING E5 1000001452
9 XA0987021 HORIZONTAL FEED PLATE
10 XA0988021 FEED STAND SHAFT
11 XA3960021 FEED STAND
12 048030346 RETAINING RING E3 1000001452
13 146200021 RETAINING RING, CS4
14 XA4430021 FEED DOG
15 060300416 SCREW BIND M3X4
16 060400816 SCREW BIND M4X8 1000017555
17 XA3474021 DUST PROTECT PLATE
18 XA4042120 FEED STAND SUPPORT
19 025040133 WASHER, PLAIN S 4 1000017555
20 XA1082051 TAPER POINT STUD R
21 XZ0074021 TAPTITE, CUP S 4X16 060158
22 XA0991021 SPRING
23 X55472021 TAPER POINT STUD L ASSEMBLY
24 XA4692021 SPRING CHG
25 XA0649021 TAPTITE, CUP S M4X14
26 X56613021 SPRING
27 XA3480021 VERTICAL FEED ARM
28 XA3481021 VERTICAL FEED ADJUSTER
29 X50559020 ZIGZAG ADJUSTING NUT CHG
30 062300806 SCREW PAN M3X8
31 060400516 SCREW BIND M4X5
32 XA0995121 VERTICAL FEED SHAFT 050091
33 048060346 RETAINING RING E6 1000001452
34 XA0030021 FEED SQUARE BLOCK CHG
35 XA0996020 FEED REGULATOR CHG
36 XA0997020 FEED REGULATOR SHAFT CHG
37 X57908021 TAPTITE, BIND S M4X10 CHG
38 XA4675021 SPRING 050091
39 XA9167021 FEED REGULATOR PLATE ASSEMBLY
40 XA1002020 REVERSE SEWING REGULATOR SHAFT
41 0A5300606 SCREW PAN (S/P WASHER) M3X6 1000011101
42 XA7989021 REVERSE SEWING LEVER PLATE
43 XA1004120 REVERSE SEWING SHAFT 050091
