6
1
Needle and presser foot
section
a Presser foot holder assembly
The presser foot is installed onto the presser foot holder
assembly.
b Presser foot screw
Use the presser foot screw to hold the presser foot
holder assembly in place.
c Presser foot (Zigzag)
The presser foot applies pressure consistently on the
fabric as the sewing takes place. Attach the appropriate
presser foot for the selected stitching.
d Feed dogs
The feed dogs feed the fabric in the sewing direction.
e Needle plate
The needle plate is marked with guides for sewing
straight seams.
f Shuttle hook
g Shuttle cover
Open the shuttle cover to set the bobbin.
h Bobbin case
i Needle
j Needle bar thread guide
k Needle clamp screw
Use the needle clamp screw to hold the needle in place.
Flat bed attachment
The accessories are stored in a compartment inside
the flat bed attachment.
a
Lift the bottom of the flat bed attachment
toward you, and then pull the flat bed
attachment out to remove it.
a Flat bed attachment
b Storage compartment
● Put the accessories in the bag, and then
store the bag inside the compartment. If the
accessories are not in a bag, they may fall
out, and be lost or damaged.
