If you accessed the service as a guest user, enter or select the account name of the user whose
documents you want to download.
For Flickr
®
:
- To download your own documents from the service, press [Your album].
- To download other users’ documents from the service, press [Other user's album], and then
enter the account name of the user whose documents you want to download.
6. Follow the on-screen instructions to complete this operation.
An album is a collection of documents. However, the actual term may differ depending on the service
you use. When using Evernote
®
, you must select the notebook, and then select the note.
Some services do not require documents to be saved in albums. For documents not saved in albums,
select [Show Unsorted Files] or [Show Unsorted Photos] to select documents. You cannot
download documents from other users if the documents are not saved in an album.
MFC-J2730DW/MFC-J5730DW/MFC-J5930DW
1. Insert a USB flash drive into your machine.
The LCD screen automatically changes.
2. Press [Web].
If information regarding the Internet connection appears on the machine's LCD, read the information
and press [OK].
Occasionally, updates or announcements about Brother Web Connect's features will appear on the
LCD. Read the information, and then press [OK].
3. Swipe left or right or press d or c to display the service that hosts the document you want to download.
Press the service name.
4. Do one of the following:
To log on to the service with your account, swipe up or down or press a or b to display your account
name, and then press it. If the PIN entry screen appears, enter the four-digit PIN and press [OK].
To access the service as a guest user, swipe up or down or press a or b to display [Use Service as a
Guest User], and then press it. When the information regarding access as a guest user appears, press
[OK].
5. Press [Download to Media].
If you accessed the service as a guest user, enter or select the account name of the user whose
documents you want to download.
For Flickr
®
:
- To download your own documents from the service, press [Your album].
- To download other users’ documents from the service, press [Other user's album], and then
enter the account name of the user whose documents you want to download.
6. Follow the on-screen instructions to complete this operation.
An album is a collection of documents. However, the actual term may differ depending on the service
you use. When using Evernote
®
, you must select the notebook, and then select the note.
Some services do not require documents to be saved in albums. For documents not saved in albums,
select [Show Unsorted Files] or [Show Unsorted Photos] to select documents. You cannot
download documents from other users if the documents are not saved in an album.
Related Information
Brother Web Connect
536

Table of Contents

Other manuals for Brother MFC-J6930DW

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother MFC-J6930DW and is the answer not in the manual?

Brother MFC-J6930DW Specifications

General IconGeneral
N-up printing2, 4, 9, 16, 25
Duplex printingYes
Print technologyInkjet
Maximum resolution1200 x 4800 DPI
Print speed (ISO/IEC 24734) mono22 ipm
Print speed (ISO/IEC 24734) color20 ipm
Time to first page (black, normal)6 s
Duplex print speed (ISO/IEC 24734) mono12 ipm
Duplex print speed (ISO/IEC 24734) color11 ipm
Print speed (black, normal quality, A4/US Letter)35 ppm
Print speed (color, normal quality, A4/US Letter)27 ppm
Copier resize25 - 400 %
Maximum copy resolution600 x 600 DPI
Copy speed (black, normal quality, A4)12 cpm
Copy speed (color, normal quality, A4)9 cpm
Scan toE-mail, E-mail Server, FTP, File, Image, OCR, USB
Scan driversSANE, TWAIN, WIA
Scanner typeFlatbed & ADF scanner
Grayscale levels256
Input color depth48 bit
Output color depth24 bit
Image formats supportedJPG
Maximum scan resolution19200 x 19200 DPI
Optical scanning resolution1200 x 2400 DPI
FaxingMono faxing
Fax memory200 pages
Modem speed33.6 Kbit/s
DisplayLCD
Control typeTouch
Product colorBlack
Display diagonal3.7 \
Market positioningBusiness
Internal memory256 MB
Card reader integratedNo
Paper tray media typesGlossy paper, Plain paper, Recycled paper, Thin paper
Non-ISO print media sizesFolio
ISO A-series sizes (A0...A9)A3, A4, A5, A6
Maximum ISO A-series paper sizeA3
Standard interfacesEthernet, NFC, USB 2.0, Wireless LAN
USB 2.0 ports quantity1
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security featuresAPOP, SMTP-AUTH, SSL / TLS (IPPS, HTTPS, FTPS, SMTP, POP3, IMAP4), SNMP v3 802.1x (EAP-MD5, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS), Kerberos
Cabling technology10/100Base-T(X)
Security algorithms64-bit WEP, 128-bit WEP, 802.1x RADIUS, SMTP-AUTH, WPA-PSK, WPA2-PSK
Ethernet LAN data rates10, 100 Mbit/s
Online services supportedDropbox, Evernote, Facebook, Flickr, Google Drive, OneDrive, OneNote
Mobile printing technologiesApple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Package depth568 mm
Package width681 mm
Package height500 mm
Package weight28300 g
Power consumption (off)0.04 W
Power consumption (sleep)1.7 W
Power consumption (standby)6.5 W
Power consumption (average operating)29 W
Sustainability certificatesBlue Angel, ENERGY STAR
Paper input typePaper tray
Total input capacity250 sheets
Total output capacity100 sheets
Auto document feeder (ADF) input capacity50 sheets
Digital sender-
Maximum duty cycle30000 pages per month
Recommended duty cycle250 - 2000 pages per month
Mac operating systems supportedMac OS X 10.9 Mavericks
Mobile operating systems supportedAndroid
Windows operating systems supportedWindows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Bundled software- Brother Control Center Version 4 - Nuance PaperPort Version 14 - Brother Control Center Version 2
Noise level50 dB
Harmonized System (HS) code84433100
Weight and Dimensions IconWeight and Dimensions
Depth477 mm
Width575 mm
Height375 mm
