4. SCREW TORQUE LIST
Location of screw Screw type Q’ty
Tightening torque
N·m (kgf·cm)
Side cover R Taptite bind B M4x12 1
0.8±0.1 (8±1)
Inner chute ASSY Taptite bind B M4x12 2
0.8±0.1 (8±1)
Side cover L Taptite bind B M4x12 1
0.8±0.1 (8±1)
Handset holder ASSY
(For models with handset)
Taptite bind B M4x12 2
0.8±0.1 (8±1)
Upper handset holder
(For models with handset)
Taptite cup B M3x8 1
0.5±0.1 (5±1)
FB ground harness Screw cup M3x8 (black) 1
0.45±0.05 (4.5±0.5)
Panel ground harness
ADF ground harness
(For models with ADF)
Screw cup M3x8 (black) 1
0.45±0.05 (4.5±0.5)
Hinge ASSY L (For models with ADF)
Taptite bind B M4x12 (black)
1
0.8±0.1 (8±1)
Hinge ASSY L (For models with ADF)
Taptite bind B M4x12 3
0.8±0.1 (8±1)
Hinge R support
(For models with ADF)
Taptite cup B M3x10 1
0.5±0.1 (5±1)
Hinge arm R (For models with ADF) Taptite cup B M3x10 3
0.5±0.1 (5±1)
ADF front cover
(For models with ADF)
Taptite cup B M3x10 2
0.5±0.1 (5±1)
ADF separation holder ASSY
(For models with ADF)
Taptite cup B M3x10 1
0.5±0.1 (5±1)
Upper document chute
(For models with ADF)
Taptite cup B M3x10 6
0.5±0.1 (5±1)
ADF ground harness
(For models with ADF)
Screw cup M3x6 (black) 1
Hinge arm L
(For models without ADF)
Taptite cup B M3x10 3
0.5±0.1 (5±1)
Hinge arm R
(For models without ADF)
Taptite cup B M3x10 3
0.5±0.1 (5±1)
Panel unit Taptite cup B M3x10 4
0.5±0.1 (5±1)
Shield plate cover
(Touch panel models)
Taptite cup B M3x10 4
0.5±0.1 (5±1)
Panel key PCB presser
(Touch panel models)
Taptite cup B M3x10 4
0.5±0.1 (5±1)
Document scanner top cover Taptite bind B M4x12 6
0.8±0.1 (8±1)
Modem ground harness LVPS Screw cup M3x8 (black) 2
0.45±0.05 (4.5±0.5)
Modem ground harness main Screw cup M3x8 (black) 2
0.45±0.05 (4.5±0.5)
Modem shield plate Taptite bind B M4x12 2
0.8±0.1 (8±1)
Modem shield cover Screw cup M3x8 (black) 1
0.45±0.05 (4.5±0.5)
Modem PCB ASSY Screw cup M3x8 (black) 3
0.45±0.05 (4.5±0.5)
Joint cover ASSY Taptite bind B M4x12 4
0.8±0.1 (8±1)
Fuser unit Taptite pan B M4x14 2
0.8±0.1 (8±1)
LVPS shield plate cover Screw cup M3x8 (black) 2
0.45±0.05 (4.5±0.5)
Screw pan M4x8 1
0.45±0.05 (4.5±0.5)
Ground harness Screw pan M4x8 1
0.45±0.05 (4.5±0.5)
