Page #122 background imageLoading...
Page #122 background image
2-82
Confidential
Paper jam at the eject section
<User Check>
Check that the paper is set in each paper tray correctly.
Flip over the paper in each paper tray or rotate the paper 180°.
Adjust each paper guide according to the paper size.
Check that there is not too much paper set in each paper tray.
Check that the thickness of the paper is 60 to 163 g/m
2
for the paper tray,
and 60 to 230 g/m
2
for the MP tray.
Flip through the paper and reset it in the paper tray.
Paper jam at the duplex tray
<User Check>
Flip over the paper in each paper tray or rotate the paper 180°.
Check that the thickness of the paper is 60 to 105 g/m
2
for the duplex tray.
Flip through the paper and reset it in the paper tray.
Use paper specified by the manufacturer.
Check that the paper size is matched to the setting for the duplex printer.
Step Cause Remedy
1
Foreign object in the rear of the
machine
Remove the foreign object.
2 Eject actuator coming off Reattach the eject actuator.
3
Connection failure of the eject
sensor harness
Reconnect the eject sensor harness.
4 Fuser cover attachment failure Reattach the fuser cover.
5 Eject sensor failure Replace the eject sensor PCB ASSY.
6 Paper feed motor failure Replace the paper feed motor.
7
Damaged gears in the paper
feed drive system
Replace the frame L unit.
8 Damaged fuser unit Replace the fuser unit.
9 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
Foreign object in the duplex
paper feeding system
Remove the foreign object.
2 Fuser cover attachment failure Reattach the fuser cover.
3 Back cover failure Replace the back cover.
4 Duplex tray failure Replace the duplex tray.
5 Main PCB failure Replace the main PCB ASSY.
