Brother MFC-L2710DN Service Manual

5-19
Confidential
1.3.11 Set PC print functions (Function code 43)
<Function>
This function is used to change the settings of the various print functions summarized in the
table below.
<Operating Procedure>
(1) Press the [4], and then the [3] in the initial state of maintenance mode. For models
without keypad, press the [▲] or [▼] to display “MAINTENANCE 43” on the LCD and
press the [OK]. “Manual Feed” is displayed on the LCD.
(2) Press the [▲] or [▼] to display the function you want to change the setting of, and press
the [SET] or [OK].
(3) For fixed parameters (On/Off, etc.), press the [▲] or [▼] to display the setting you want
to apply, and press the [SET] or [OK].
For parameters requiring numerical value entry, use the keypad to enter a numerical
value if the model has it, and press the [SET].
For models without keypad, press the [▲] or [▼] to change the selected number (0 to 9).
(4) When the [X] or [Stop] is pressed, the machine returns to the initial state of maintenance
mode.
 Setting functions
The available functions change depending on the corresponding emulation.
(For the emulation specifications, refer to “1. GENERAL” in Chapter 1.)
<For models with emulation>
LCD Description Set value Default
Common functions
Manual Feed Manual feed setting On/Off Off
Resolution Print resolution 300/600/1,200 dpi 600 dpi
Toner Save Toner save mode setting On/Off Off
Density Print density level -6 to 6 0
Job Cancel
TimeOut
Time until host timeout after
a job is canceled
0 to 255 seconds 4 seconds
Sleep Time Time until engine sleep
mode is entered
0 to 99 minutes 5 minutes
Page Protection Page memory setting Off/LTR/A4/LGL/Auto Off
Emulation Emulation (print language)
setting
Auto/HP/PS Auto
Auto I/F Time Interface open time setting 1 to 99 seconds 5 seconds
Media Type Paper type setting Thin/Plain/Thick/Thicker/
Transparency/Recycled/
Bond/Envelopes/EnvThin/
EnvThick
Plain
or
Thin
Paper Size Image development area
setting
Letter/Legal/A4/Exec/B5/
JISB5/A5/B6/A6/Monarch/
C5/COM10/DL/DLL/A4Long/
Hagaki/Folio
Letter
or
A4
Copies Number of copies 1 to 99 copies 1 copy
