2-17
Confidential
3. ERROR INDICATIONS
This machine includes a self-diagnosis function. If the machine does not work normally it judges
that an error has occurred, and indicates the corresponding error message on the LCD, which
in turn helps the service personnel to quickly find out the problem.
3.1 Error Codes
The shaded errors hardly occur under normal use. They may be caused by noise around the
installation site, variation in power supply voltage, or software failure.
Error
Codes
Description
Refer
to:
Error
Codes
Description
Refer
to:
0101 --- 050A
The hardware detected a temperature
error through the center thermistor or
the side thermistor of the fuser unit.
2-49
0102
ASIC error or motor driver error
occurred.
2-47 050B
When the center thermistor of the fuser
unit was lower than the idle temperature,
the side thermistor detected a temperature
higher than the specified temperature.
2-49
0201
Cannot detect the synchronized signal
of the paper feed motor. The speed of
the paper feed motor does not stabilize
within the specified time.
2-47 050C
When the center thermistor of the fuser
unit was higher than the idle temperature,
the side thermistor detected a temperature
lower than the specified temperature.
2-49
0202 ---
050D ---
0203 ---
0300
Cannot detect the lock signal of the polygon
motor for the laser unit. (second time)
2-47 050F ---
0305
Cannot detect the lock signal of the
polygon motor for the laser unit. (first time)
2-47 0800 ---
0401 BD sensor failure (second time) 2-48 0900
Detected irregular power supply for
more than 100 times.
2-50
0402 --- 0A01 ---
0405 BD sensor failure (first time) 2-48 0A02 Detected a fan failure. 2-50
0501
The center thermistor of the fuser unit
has not reached the specified
temperature within the specified time.
2-49
0A03 ---
0502
The center thermistor of the fuser unit has
not reached the specified temperature
within the specified time after it was
heated normally to the certain level.
2-49 0B01
An error occurred in the high-voltage
power supply PCB ASSY while
operating.
2-51
0503
The center thermistor of the fuser unit
detected a temperature higher than the
specified value.
2-49 0B02
An error occurred in the high-voltage
power supply PCB ASSY when the
machine was in the ready state.
2-51
0504
After the heat unit was heated
normally, the center thermistor of the
fuser unit detected a temperature
lower than the specified value.
2-49
0C00 ---
0505
The center thermistor of the fuser unit
detected a temperature rise greater than
the specified value within the specified time.
2-49 0D01 ---
0506
The center thermistor of the fuser unit
detected a temperature fall greater than the
specified value within the specified time.
2-49 0D02 ---
0508
Temperature of the end part didn’t rise
by 1 °C when the fuser unit heater was
turned ON.
2-49
0D03 ---
