CONTENTS
(1) PRINCIPAL PARTS............................................................... 2
(2)
UPPER SHAFT / NEEDLE BAR, PRESSER MECHANISM
.... 4
(3)
FEED, ROTARY HOOK / THREAD CUTTING MECHANISM
.... 6
(4)
ROTARY HOOK DRIVE / BOBBIN WINDER MECHANISM
.... 8
(5) THREAD GUIDE MECHANISM........................................... 10
(6) ELECTRONIC PARTS / MOTOR UNIT............................... 12
(7) EMBROIDERY UNIT ........................................................... 14
(8)
ATTACHMENTS / PRINTED MATTER / PACKING MATERIALS
.... 16
NEEDLE-PRESSER MODULE............................................ 18
FEED MODULE................................................................... 20
THREAD CUTTER MODULE .............................................. 22
Note on parts:
We keep performance parts for this sewing machine for at least 8 years after this model is discontinued.
Performance parts are the necessary parts to maintain the function of the sewing machine.
