Brother PE780D - UPPER SHAFT; NEEDLE BAR, PRESSER MECHANISM; UPPER SHAFT MECHANISM; NEEDLE BAR, PRESSER MECHANISM

- 4 -
(2) UPPER SHAFT / NEEDLE BAR, PRESSER MECHANISM
No. CODE NAME REMARKS
UPPER SHAFT MECHANISM
1 XC3246151 UPPER SHAFT ASSY
2 XC2375051 PULLEY
3 048060346 RETAINING RING, E6
4 XC2380020 UPPER SHAFT PULLEY
5 XC2383021 FIXED JOINT
6 012500532 SET SCREW, SOCKET (FT) M5X5
7 132421021 BUSHING PRESSER
8 X57908021 TAPTITE, BIND S M4X10
9 XC2384051 TIMING BELT 420-5GT-6
10 XC2385051 TENSION PULLEY ASSEMBLY
11 138172021 SCREW, PAN(S/P WASHER)M4X10
12 XD0362051 NP PCB ASSY FCOM
13 X59629021 TAPTITE, BIND B M3X10
14 XC2390251 PCB HOLDER
15 060400816 SCREW, BIND M4X8
16 XC3028051 INSULATION SHEET
17 014400432 SET SCREW, SOCKET (CP) M4X4
18 XD0587051 BELT GUARD
19 XC3183051 FELT
20 137947001 CLIP
NEEDLE BAR, PRESSER MECHANISM
21 XC2503051 SHAFT
22 XC2297051 PRESSER PLATE A
23 XC2298051 PRESSER PLATE B
24 X57908021 TAPTITE, BIND S M4X10
25 XC2504050 ADJUSTING SCREW
26 XZ0380051 SCREW, PAN (WASHER) M3X18
27 XC2505050 PLATE SPRING
28 060400516 SCREW, BIND M4X5
29 XE6361001 PCB UNIT: LED LAMP-FL
30 XZ0149021 TAPTITE, PAN B 4X12
31 048050346 RETAINING RING, E5
