KNOWING YOUR SEWING MACHINE ————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
————————————————————————————————————————————————
15
Feed dog position switch
Use the feed dog position switch to raise or lower the
feed dogs according to the job that is being done. When
darning or sewing on buttons, the feed dogs should be
lowered. (The garment will not be fed.)
● When raising or lowering the feed dogs,
move the feed dog position switch as far as
possible to the appropriate side. Since the
feed dogs can not be lowered using the feed
dog position switch immediately after they
are raised, turn the handwheel toward you
(counterclockwise) once and after the feed
dogs are raised, lower them using the feed
dog position switch.
1 Feed dog position switch
2 Down position
3 Up position
THREADING THE MACHINE
Winding the bobbin
1
23
● We designed the bobbin that comes with this machine. If you use bobbins from other models,
the machine will not work properly. Only use the bobbin that comes with this machine or
bobbins of the same type (part code: SA156, SFB: XA5539-151). Using other bobbins may
cause damage to the machine.
Actual size
11.5 mm
(7/16 inch)
This model Other models
1 Hook of the
bobbin-winding
thread guide
2 Pre-tension disk
3 Bobbin winder
shaft
4 Bobbin
To Next Page
