OPERATING HANDLE STORED POSITION
IMPORTANT
When it is required to fold up the handle, for storage or transport, remove the LOWER
BOLT to allo
w the handle to pivot over-center and remain in position.
If the unit is to be transported long distances or over bumpy surfaces a shock cord from the
handl
e to the frame will provide extra security.
Fig.7
9
