Brouwer BTR 30 - Page 19

ITEM
NO.
PART NO.
DESCRIPTION
QTY
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
TR30033
TR30010
TR30180
TR30183
TR10055
TR10056
TR30237
TR30083
D001-161
D001-160
D001-033
D001-073
D001-109
D001-054
TR10072
D001-158
F040610
F041016
F321000
F211000
F040840
F320800
F210800
F040410
F320400
F210400
KB32016
KH00015
D001-043
F310600
D001-133
KH00026
TR10320
F940224
KX50105
BTR 30 TURF ROLLER
FRAME AND ROLLERS ASSEMBLY
Roller Housing
Roller - 24 in. Dia. (Traction)
Roller - 24 in. Dia. (Smooth)
Roller - 24 in. Dia. (Traction. Heavy Duty)
Scraper - 24in. Roller
Scraper - 8in. Roller
Roller - 8in. Dia.
Handle
Decal - Brouwer. 12 in.
Decal - Brouwer 6in.
Decal - "Warning to Prevent Serious…"
Decal - "Caution to Prevent tipping…"
Decal - "R - N - F"
Decal - "Warning Crushing Hazard…"
Bearing Mounting Bracket
Serial No. Plate
Bolt 3/8 unc x 1 Gr.8
Bolt 5/8 unc x 1 3/4 Gr. 8
Washer 5/8
Locknut 5/8 unc
Bolt 1/2 unc x 4 Gr.8
Washer 1/2
Locknut 1/2 unc
Bolt 1/4 unc x 1 Gr.8
Washer 1/4
Locknut 1/4 unc
Flange Bearing
Pipe Plug 3/4 NPT. Sq. Hd.
Reflector Tape - Orange. (Not Illustrated)
Lockwasher 3/8
Decal - "Important Allow air to vent…"
Plug Recessed 2 NPT. Plastic
Pin. Free Wheeling.
Hitch Pin Clip.
Push Cap Nut.
1
1
1
1
1
1
1
1
1
2
1
1
1
2
2
1
4
4
4
4
2
4
2
4
8
4
2
1
1
4
1
1
1
1
1
19/03/2020
2
