Brouwer BTR 30 - Page 23

ITEM
NO. PART NO. DESCRIPTION QTY
BTR 30 TURF ROLLER
CONTROLS ASSEMBLY
1 F900404 Woodruff Key 1/8 x 1/2 Pan. Hd. Phil. S.S. 1
2 TR30045 Lever Arm 1
3 F230600 Nut 3/8 UNC (Locite) 1
4 KM99002 Clevis Cable End c/w Pin, Cotter Pin & Bushing 1
5 KD10033 Control Cable Ass'y 1
6 F220450 Jam Nut 1/4 - 28 UNF 1
7 F010512 Bolt 5/16 UNC x 1 1/4 2
8 F310500 Lockwasher 5/16 2
9 F230500 Nut 5/16 UNC 4
10 F320500 Washer 5/16 4
11 TR50195 F-N-R Control Assembly c/w Cable 1
KD10027 Control Assembly. F-N-R 1
12 F040522 Bolt 5/16 unc x 2 1/2 Gr.8 2
13 F320500 Washer 5/16 2
14 F210500 Locknut 5/16 2
15 KD40025 Switch 'ON-OFF' (Honda Part) 1
16 TR50188 Loom 'ON-OFF' Switch to Engine Ref
17 KB10404 Bushing 1
18 KD10044 Control Assembly. Service Kit 1
19 KM99055 Knob 1
6
NOTE
Item 18 - Control Assembly Service
Kit includes a Bolt, Lockwasher,
Cable End Bushing - KB10422, and
Snap Ring - F830425.
NOTE
