Brouwer BTR 30 - Page 25

ITEM
NO. PART NO. DESCRIPTION QTY
BTR 30 TURF ROLLER
ENGINE & TRANSMISSION ASSEMBL
Y
1 KM30012 Plug 1
2 F010516 Bolt 5/16 UNC x 1 3/4 4
3 F320500 Washer 5/16 8
4
F210500
Locknut 5/16 UNC
4
5 F923310 Key 3/16 x 3/16 x 1 (Engine shaft) 1
6 D001-115 Decal - "Important Check Oil Level…" 1
7 F140502 Set Screw UNC 5/16 Soc. Hd. 2
8 KD85104 Coupling Insert 1
9 TR10028 Half Coupling (Transmission) 1
10 F140402 Set Screw 1/4 UNC Soc. Hd. 2
11 F900404 Woodruff Key 1/8 x 1/2 Pan. Hd. Phil. S.S. 2
12 F700204 Screw #10 - 24 x 1/2 4
13 F310200 Lockwasher #10 4
14 TR10177 Cooling Fan 1
15 KD40017 Transmission (Eaton Model 7) 1
16 F010632 Bolt 3/8 UNC x 3 1/4 4
17 F210600 Locknut 3/8 UNC 4
18 F320600 Washer 3/8 8
19 TR10029 Sprocket (Transmission Shaft) 1
20 F140402 Set Screw 1/4 UNC Soc. Hd. 2
21 F900404 Woodruff Key 1/8 x 1/2 1
22 D001-068 Decal - "Important Use Synthetic…" 1
23 D001-053 Decal - "Caution Hot Exaust…" 1
24 TR30033 Roller Housing 1
25 TR10030 Fan Shroud 1
26 TR30039 Chain Guard 1
27 F040610 Bolt 3/8 unc x 1 Gr.8 4
28 F310600 Lockwasher 3/8 4
29 F040410 Bolt 1/4 unc x 1 Gr.8 2
30 F320400 Washer 1/4 2
31 F310400 Lockwasher 1/4 2
32 D001-134 Decal - "Warning Freewheel Control…" 1
33 D001-146 Decal - "Important Keep Hydrostatic Transmission clean…" 1
34 KD40019 Honda Engine GX 160 - See Note on Front Page of Parts List 1
35 D001-054 Decal - "Warning Crushing Hazard…" 1
36 F140502 Set Screw 5/16 unc x 1/4 2
37 TR10239 Half Coupling (Engine) 1
38 TR10320 Pin. Free Wheeling 1
39 F940224 Hitch Pin Clip 1
40 KX50105 Push Cap Nut 1
8
41 F040634 Bolt 3/8 N.C. x 3 1/2 Lg. - Current 1
42 F210608 Locknut 3/8 N.C. - Current 1
43 F23009 Coupling Nut 3/8 N.C. - Current 1
44 F040606 Bolt 3/8 N.C. x 3/4 Lg. - Current 1
Items 41, 42, 43 & 44 are
Current from Mid April 2017
NOTE
16-May-17
