Brouwer BTR 30 - Model 7 Transmission Parts List

ITEM
NO. PART NO. DESCRIPTION QTY
EATON MODEL 7 HYDROSTATIC TRANSMISSION
1 KH70055 Transmission Overhaul Kit
1A KD40023 Transmission Reservoir Kit 1
2 103531 Reservoir Cover 1
3 104322 Reservoir Body 1
4 104068 Reservoir Diaphragm 1
5 008771-130 Square Cut Seal Ring 1
6 990176 Cover Sevice Kit 1
7 93881 Pivot Pin Dowel 1
8 096098-062 External Retaining Ring 1
9 95060 Control Shaft Washer 1
10 101597 Button 1
11 24234 'O' Ring Fitting Guide Sub-assembly 1
12 008761-010 'O' Ring 1
13 24166 Bracket - Pins Sub-assembly 1
14 72149 Valve Spring 2
15 008771-162 Square Cut Seal Ring 1
16 22712 Pump Rotor - Ball Sub-assembly 1
17 40520 Pump Race 1
18 102623 Cam Ring 1
19 102451 Piston 2
20 088770-113 Back-up Ring 2
21 008765-113 'O' Ring 2
22 102454 Pintle Sub-assembly 1
23 104111 Motor Rotor- Ball Sub-assembly 1
24 101680-156 Retaining Ring 1
25 97121 Snap Ring 1
26 90797 Ball Bearing ( Input ) 1
27 62184 Input Shaft 1
28 93955 Oil Seal 1
29 82112 Gasket 1
30 24235 Nut - Gasket Sub-assembly 1
31 62240 Dump Valve Shaft 1
32 93895 Oil Seal 1
33 990083 Control Shaft Kit 1
34 990083 Dowel 3/8 dia. x 1 3/4 lg. 1
35 95203 Cam Ring Insert 1
36 098294-075 Coil Pin 5/16 dia. x 3/4 lg. 1
37 70130 Check Valve Body 2
38 0095881-031 Grade 200 Ball 5/16 dia. 2
39 95214 Retaining Ring 2
40 70044 Piston Spring 5
41 025090-006 'O' Ring Plug Sub-assembly 1
42 008785-006 Tube Fitting 'O' Ring 1
43 32278 Body 1
44 93955 Oil Seal 1
45 90797 Ball Bearing ( Output ) 1
46 101680-156 Retaining Ring 1
47 22892 Output Shaft Sub-assembly 1
48 N/A Woodruff Key #3 1
14
Items 1A & 1 can be ordered from
Kesmac parts department.
ALL OTHER TRANSMISSION PARTS
ARE LISTED FOR CUSTOMER
CONVENIENCE, BUT MUST BE
ORDERED FROM THE EATON AREA
DEALER.
go to www.eatonhydraulics.com for
more information
NOTE
