Replacement Parts
39
Deck Assembly - All Models (continued)
Ref. No. Part No. Qty Description
1 170-232-0860 1 5 Foot Deck Weldment
2 232-8110 1 Hydraulic Drive Guard
3 HC58C24Z 4 Bolt 1/2”-13 x 1 1/2” Grade 5 Zinc)
4 WSA50Z 4 Flat Washer SAE 1/2” Grade 5
5 232-0860 1 Blade Bar
6 UK-905 4 Blades Priced each, sold in pairs only
7 TC-133KL 4 Bolt Kits - Sold in Sets Only
8 233-82027 1 Hydraulic Motor
9 HC88C44Z 4 Bolt 1/2”-13 x 2 3/4”” Grade 8 Zinc (Motor to Bearing Housing)
10 NNE850CZ 4 Nylon Lock Nut, 1/2”-13 Grade 8 Zinc (Motor to Bearing Housing)
11 WSA50Z8 4 Flat Washer SAE 1/2” Grade 8 (Motor to Bearing Housing)
12 235-6000 1 Bearing Housing (under guard) see page 40 for details
13 HC812F64Z 6 Bolts 3/4-16 x 4” Grade 8 Zinc NF (Bearing Housing to Deck)
14 NNE34FZ 6 Nylon Lock Nut 3/4-16 Zinc NF (Bearing Housing to Deck)
15 233-232-8200 1 Standard Flow Hose Package
16 MH-01 1 Manual Tube Holder/ Serial Plate Mount
17 CB5516C12Z 2 Carriage Bolt 5/16 -18 x 3/4 Grade 5 Zinc (For MH-01)
18 NNE516CZ 2 Nylon Lock Nut 5/16-18 Zinc For (MH-01)
19 5/16” CHAIN 6 ft. Lift Restriction Chain (See Page 17 for Installation)
20 233-232-8005 2
#12 MBX-72”OAL-#12 FJX Sleeved
21 233-232-8010 1
#6 FJX90-120”OAL-#8MBX Sleeved
22 233-232-8000 2 #12 MBX-36"OAL-#12FJX Sleeved
23 233-6600-12-12-12 2 3/4” JIC Female Swivel Branch Tee
24 233-DT-1000-MF-MF-5 1 Check Valve Short, 1” JIC Male
25 233-4HTOF6 1 1/2” Female Coupler #12 SAE Flat Face Coupler ORB
26 233-HT4OF6 1 1/2” Male Nipple #12 SAE Flat Face Coupler
27 233-3HTOF4 1 3/8” Female Coupler, #8 Flat Face Coupler
28 233-232-8200 1 Standard Flow Hose Hose Package
29 233-9002-06-04 1 3/8” JIC Male x 1/4” BSPP Male Adapter ( Motor End Case Drain)
30 232-0840 1 Case Relief Valve Kit
