Broyhill SANDPOINTE - Page 30

Assembled View:
Connect lower baffle of inclined beam (Q),
inclined beam lower cover plate (V2) and
bottom skew beam (F2) using bolt (GG) and
flat washer (CC), tighten with wrench (Z1).
67(3
30/31
4X
4X4X
