POWERHEAD
UPPER MOUNT SERVICING
10
UPPER MOUNT
SERVICING
Removal
Remove mount retainer screw.
.
Tap the edge of one of the mount housings with a
large, blunt punch to loosen the mount retainer.
Dislodge mount assemblies and remove.
Inspect mounts and replace if necessary.
IMPORTANT: The motor mount, washer, and
screw are serviced as an assembly. Do not disas-
semble.
1. Mount retainer screw 005309
WARNING
Wear safety glasses to avoid injury.
005311
1
005312
39820
