14
B. THE HELMET
REMOVING THE HEAD LINER
1. First, remove the rear portion of the
head liner. The head liner is attached to
the inner shell with 2 snaps (on each
side of the neck) and a frontal portion,
with 3 plastic strips.
2. Then you can remove the frontal
portion by pulling the 3 plastic strips out
carefully. For the frontal portion, start to
pull from one side of the plastic strip.
INSTALLING THE HEAD LINER
1. Insert the frontal plastic strip under
the notches of the other plastic strip
attached to the inner shell.
2. Next, position the head liner inside
the helmet.
3. Then, fasten the 2 snaps on the neck
portion.
Never ride when parts of the inner
lining have been removed.
To avoid damage to the inner lining and inner shell, do not hang the
helmet over the mirrors or handlebar grips.
