d06856.fm
SB-912-074 / SB-914-056
SERVICE BULLETIN
03 December 2020 73-00-00
Initial Issue Page 9 of 12
Copyright - BRP-Rotax GmbH & Co KG. All rights reserved.
NOTE: In case of contaminations of the float chambers first the cause must be found and the
relevant measures need to be taken. Possibly the whole fuel system including carbu-
retors needs to be cleaned and checked.
Fig. 2
8140
1 Drip tray
2 Floats
3 Gasket
4 Float chamber
5 Spring clip
6 O-ring
7 Attachment screw
2
1
3
4
5
6
7
