MAINTENANCE MANUAL LINE
ENGINE CONTROL UNIT (ECU)
Safety notice
m WARNING
Non-compliance can result in serious injuries or death!
When working on the ECU, the general safety instruction must be observed. See chap-
ter „INTRO“.
Figure 7.4: Engine control unit (ECU)
1
Engine control unit (ECU)
2 Rubber isolator
3 Socket for AMP-connector
CHECKING ECU
Instruction For checking proceed as follows:
Step
Procedure
1
Inspect the ECU (1) and ECU mounts (2) for secure attachment and
damage.
2
Inspect the ECU wiring for wear, chafing and other damage, and make sure
that the connectors are securely attached.
Effectivity: 916 i A / C24
Edition 0/Rev. 1
12–20–00
Page 13
December 01 2023
