READ OUT THE ECU DATA MEMORY
Instruction To read out the ECU data memory proceed as follows:
Step
Procedure
1 Connect the decoding unit (Dongle) with ECU data cable to the computer.
2
Select the menu item BUDS in the maintenance software and print out the
report.
NOTE
Connect and disconnect the B.U.D.S. USB-to-CAN Converter only if ECU is OFF.
Non-compliance leads to entries in the error / event memory of the ECU.
See Maintenance Manual Heavy (MMH) Chapter 76–10–00.
CHECKING THE AC-DC CONVERTER WARNING LAMPS
Instruction
916 i TYPE C24
Step
Procedure
1
Turn “ON” the Battery. The 14 V output (EMS) and 28 V output (AC) warn-
ing lamp should be illuminated.
2 Activate the start power switch. The start power and the 28 V output warn-
ing lamps should be illuminated. The 14 V output (EMS) should turn “OFF”.
3 Start the engine and deactivate the starter power switch. Let the engine run
on 3000 rpm for 2 minutes. All three warning lamps should stay “OFF”.
NOTE
In case the warning lamps stay “ON”, the wiring and electric components of the
power supply have to be checked and corrected.
12–20–00
Page 14
December 01 2023
Effectivity: 916 i A / C24
Edition 0/Rev. 1
