S1 TITAN, T
RACER
5, and CTX User Manual
030.0
112.04.0
16 of 67
windows,
CTX
Step
Act
ion
1
Peel o
ff the old window and remove adhesive with
isopr
opyl
alcohol. Av
oid any contact with the sensitive detector.
2
Peel the
white backing from the new 3.0

m Prol
ene Thin Film
42mm diameter window, part number 160.0181.01.
Caution: The Etnom film window looks identical but do not
use it here. See CTX Windows at the bottom of page 8.
3
Carefu
lly
appl
y the new window
within th
e circular indent.
4
To secure the window, press the edge all the way around.
