Brunetti MC2 MASTER COMBO - Rear Panel External Connections; Connecting External Amps (Send); Connecting External Preamps (Return); External Speaker Connection

REAR PANEL
HOW TO USE THE SEND
In the normal use the SEND output can be used to connect an external power amp and its cabinet
together to the combo. (See example).
HOW TO USE THE EXT SPKR
EXT SPKR allows you to use an external speaker together to the internal one.
Pay attention to set the right impedance.
CABINET 1x12''
16Ω
In
PRE AMP
Out
Guitar
16Ω
CABINET 4x12'' MONO
In
POWER AMP
Out
Select on the power amp
the same impedance value
of the cabinet
(in this example 16 ohm).
