Copyright 5/09 PAGE 67
MODELS 2000XP / 2100SP
IGNITION POSITION
OUT TO STARTER
FROM KEY SWITCH ON POSITION
OUT TO STARTER
10 AMP10 AMP
A
B
55
6
3
2
1
4
2 PIN WEATHER PACK CONNECTOR TO CLUTCH
BLACK
CLUTCH SWITCH
YEL/RED
YELLOW
BLUE
BLUE
IN FROM KEY SWITCH IGNITION POSITION IN FROM KEY SWITCH
SPECIFIC SCHEMATIC FUNCTION MAY VARY DEPENDING
ON OPTIONS OR COMPONENT MANUFACTURER.
ELECTRICAL SCHEMATIC (991-8000-06)
MODEL 2000XP
ELECTRICAL SECTION
