CONDENSER ONLY RATINGS
SST
°F(°C)
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
55 (12.78) 65 (18.33) 75 (23.89) 85 (29.44) 95 (35.0) 105 (40.56) 115 (46.11) 125 (51.67)
126BNA018****A
30
( --- 1.11)
TCG 15.70 14.90 14.10 13.20 12.30 11.30 10.20 9.20
SDT 66.60 76.20 85.80 95.30 104.80 114.30 123.70 133.10
KW 0.75 0.87 0.99 1.12 1.26 1.41 1.60 1.81
35
(1.67)
TCG 17.50 16.60 15.70 14.70 13.70 12.60 11.50 10.30
SDT 67.80 77.30 86.80 96.30 105.70 115.10 124.40 133.80
KW 0.75 0.87 0.99 1.12 1.26 1.42 1.60 1.81
40
(4.44)
TCG 19.40 18.40 17.40 16.30 15.20 14.00 12.80 11.50
SDT 69.00 78.50 87.90 97.30 106.60 115.90 125.20 134.50
KW 0.74 0.87 0.99 1.12 1.26 1.42 1.60 1.81
45
(7.22)
TCG 21.50 20.30 19.20 18.00 16.70 15.50 14.10 12.80
SDT 70.40 79.70 89.00 98.30 107.60 116.90 126.10 135.30
KW 0.74 0.86 0.99 1.13 1.27 1.43 1.61 1.82
50
(10.0)
TCG 23.60 22.40 21.10 19.70 18.40 17.00 15.60 14.10
SDT 71.60 80.90 90.10 99.40 108.60 117.80 127.00 136.20
KW 0.73 0.86 1.00 1.13 1.28 1.44 1.62 1.82
55
(12.78)
TCG 25.90 24.50 23.10 21.60 20.10 18.60 17.10 15.50
SDT 73.00 82.10 91.30 100.50 109.70 118.80 128.00 137.10
KW 0.73 0.86 1.00 1.14 1.29 1.45 1.63 1.84
126BNA024****A
30
( --- 1.11)
TCG 21.10 20.10 19.00 17.90 16.70 15.40 14.10 12.70
SDT 66.10 75.80 85.30 94.90 104.40 114.00 123.40 132.80
KW 1.00 1.15 1.31 1.47 1.65 1.86 2.09 2.37
35
(1.67)
TCG 23.40 22.20 21.00 19.80 18.50 17.10 15.60 14.10
SDT 67.20 76.80 86.30 95.80 105.30 114.70 124.10 133.50
KW 0.99 1.15 1.31 1.47 1.66 1.86 2.10 2.37
40
(4.44)
TCG 25.80 24.60 23.20 21.80 20.40 18.90 17.30 15.70
SDT 68.40 77.90 87.30 96.70 106.10 115.50 124.80 134.10
KW 0.98 1.14 1.31 1.48 1.66 1.87 2.10 2.37
45
(7.22)
TCG 28.50 27.00 25.50 24.00 22.40 20.80 19.10 17.40
SDT 69.60 79.00 88.30 97.70 107.00 116.30 125.60 134.90
KW 0.97 1.14 1.31 1.48 1.67 1.87 2.11 2.37
50
(10.0)
TCG 31.20 29.60 28.00 26.30 24.60 22.80 21.00 19.10
SDT 70.80 80.10 89.40 98.70 107.90 117.20 126.40 135.60
KW 0.96 1.14 1.31 1.49 1.67 1.88 2.12 2.38
55
(12.78)
TCG 34.20 32.40 30.60 28.80 26.90 25.00 23.00 20.90
SDT 72.10 81.30 90.50 99.70 108.90 118.10 127.30 136.40
KW 0.95 1.13 1.31 1.49 1.69 1.90 2.13 2.39
126BNA030****A
30
( --- 1.11)
TCG 24.90 23.50 22.20 20.80 19.40 17.90 16.20 14.40
SDT 68.10 77.50 87.00 96.40 105.80 115.10 124.40 133.60
KW 1.27 1.43 1.60 1.78 1.99 2.23 2.50 2.81
35
(1.67)
TCG 27.50 26.00 24.50 23.10 21.50 19.90 18.10 16.20
SDT 69.40 78.70 88.10 97.40 106.70 116.00 125.30 134.40
KW 1.28 1.44 1.61 1.79 2.00 2.24 2.51 2.82
40
(4.44)
TCG 30.30 28.60 27.10 25.50 23.80 22.00 20.10 18.10
SDT 70.70 79.90 89.20 98.50 107.70 117.00 126.20 135.30
KW 1.29 1.44 1.61 1.80 2.01 2.25 2.52 2.83
45
(7.22)
TCG 33.30 31.50 29.80 28.00 26.20 24.30 22.30 20.10
SDT 72.00 81.20 90.40 99.60 108.80 118.00 127.20 136.30
KW 1.29 1.44 1.61 1.80 2.01 2.26 2.53 2.85
50
(10.0)
TCG 36.50 34.50 32.60 30.70 28.80 26.70 24.50 22.20
SDT 73.50 82.50 91.70 100.80 110.00 119.20 128.20 137.20
KW 1.29 1.44 1.61 1.80 2.02 2.26 2.54 2.86
55
(12.78)
TCG 39.90 37.80 35.70 33.60 31.50 29.30 26.90 24.40
SDT 75.00 84.00 93.00 102.10 111.20 120.30 129.30 138.20
KW 1.29 1.44 1.61 1.80 2.02 2.27 2.54 2.86
126BNA036****A
30
( --- 1.11)
TCG 30.40 28.80 27.20 25.60 23.90 22.10 20.20 18.20
SDT 68.90 78.20 87.50 96.80 106.20 115.50 124.90 134.20
KW 1.49 1.72 1.95 2.21 2.49 2.81 3.20 3.64
35
(1.67)
TCG 33.50 31.80 30.10 28.30 26.50 24.50 22.50 20.30
SDT 70.10 79.30 88.60 97.90 107.20 116.50 125.80 135.00
KW 1.49 1.73 1.96 2.22 2.50 2.82 3.20 3.65
40
(4.44)
TCG 37.00 35.10 33.20 31.20 29.20 27.10 24.90 22.60
SDT 71.40 80.60 89.80 99.00 108.20 117.40 126.70 135.90
KW 1.50 1.73 1.97 2.23 2.51 2.84 3.21 3.65
45
(7.22)
TCG 40.60 38.60 36.50 34.30 32.10 29.80 27.40 24.90
SDT 72.80 81.90 91.00 100.20 109.40 118.50 127.70 136.80
KW 1.51 1.75 1.99 2.24 2.53 2.85 3.23 3.66
50
(10.0)
TCG 44.50 42.30 40.00 37.70 35.20 32.70 30.10 27.40
SDT 74.40 83.30 92.40 101.50 110.50 119.60 128.70 137.70
KW 1.53 1.76 2.01 2.26 2.55 2.87 3.24 3.67
55
(12.78)
TCG 48.70 46.20 43.70 41.20 38.50 35.80 33.00 30.00
SDT 76.00 84.90 93.80 102.80 111.80 120.80 129.80 138.70
KW 1.55 1.79 2.03 2.29 2.57 2.90 3.26 3.69
See notes on page 53
