10
DIMENSIONS -- SI
76.2
K
8.0
L
N
M
E
F
G
C
88.9
47.6
P
A
B
208-230-1-60
230-1-60
208/230-3-60
460-3-60
UNIT SERIES
ELECTRICAL
CHARACTERISTICS
ABCDEFGKLMNP
OPERATING
WEIGHT (Kgs)
SHIPPING
WEIGHT (Kgs)
SHIPPING
DIMENSIONS (L x W x H)
126BNA018 A X O O O 654.0 728.7 95.2 19.0 112.7 539.8 198.4 71.4 12.7 336.6 349.3 323.9 61.7 73.9 682.6 X 763.6 X 827.1
126BNA024 A X O O O 792.2 719.2 95.2 19.0 166.7 627.1 231.8 71.4 12.7 396.9 393.7 355.6 73.9 89.8 822.3 X 901.7 X 827.1
126BNA030 A X O O O 792.2 820.8 95.2 19.0 166.7 627.1 231.8 71.4 12.7 419.1 381.0 374.7 75.7 92.5 822.3 X 901.7 X 912.8
126BNA036 A X O O O 889.0 719.2 98.6 22.2 166.7 722.3 231.8 74.6 15.9 463.6 428.6 355.6 81.6 99.3 917.6 X 998.6 X 827.1
126BNA042 A X O O O 889.0 993.8 98.6 22.2 166.7 722.3 231.8 74.6 15.9 457.2 406.4 444.5 106.1 127.5 917.6 X 998.6 X 1085.8
126BNA048 A X O O O 889.0 820.8 98.6 22.2 166.7 722.3 231.8 74.6 15.9 431.8 444.5 355.6 112.5 132.0 917.6 X 998.6 X 912.8
126BNA060 A X O O O 889.0 1166.8 98.6 22.2 166.7 722.3 231.8 74.6 15.9 454.0 473.1 514.4 152.9 168.7 917.6 X 998.6 X 1258.9
UNIT SIZE
MINIMUM
MOUNTING PAD
DIMENSIONS
18 660.4 X 660.4
24,30 800.1 X 800.1
36 THRU 60 889.0 X 889.0
X = YES
O=NO
C, MAX. 52
AIR
DISCHARGE
AIR IN
AIR IN
AIR IN
AIR IN
9.53 TIEDOWN KNOCKOUTS
(2) PLACES
AIR DISCHARGE
SQ.
VAPOR LINE CONN.
FIELD CONTROL
SUPPLY CONN.
22.23 HOLE
FIELD POWER SUPPLY CONN.
22.23 HOLE WITH
28.58 KNOCKOUT
D
126B
