Table 15—Orifice Size* and Manifold Pressure (In. W.C.) for Gas Input Rate
(Tabulated data based on 22,000 btuh per burner, derated 4 percent for each 1000 ft. (305 M) above sea level)
ALTITUDE RANGE
FT. (M)
AVG. GAS
HEAT VALUE
AT ALTITUDE
(BTU/CU FT.)
SPECIFIC GRAVITY OF NATURAL GAS
0.58 0.60 0.62 0.64
Orifice
No.
Manifold
Pressure
Orifice
No.
Manifold
Pressure
Orifice
No.
Manifold
Pressure
Orifice
No.
Manifold
Pressure
U.S.A.
0to
2000
(0 to
610)
900 42 3.5 42 3.6 42 3.7 41 3.5
925 42 3.3 42 3.4 42 3.5 42 3.7
950 43 3.8 42 3.3 42 3.4 42 3.5
975 43 3.6 43 3.8 42 3.2 42 3.3
1000 43 3.5 43 3.6 43 3.7 43 3.8
1025 43 3.3 43 3.4 43 3.5 43 3.6
1050 44 3.6 43 3.2 43 3.4 43 3.5
1075 44 3.4 44 3.5 43 3.2 43 3.3
1100 44 3.3 44 3.4 44 3.5 43 3.2
U.S.A.
2001 to
3000
(610 to
914)
800 42 3.4 42 3.5 42 3.6 42 3.7
825 42 3.2 42 3.3 42 3.4 42 3.5
850 43 3.7 43 3.8 42 3.2 42 3.3
875 43 3.5 43 3.6 43 3.7 43 3.8
900 43 3.3 43 3.4 43 3.5 43 3.6
925 43 3.1 43 3.2 43 3.3 43 3.4
950 43 2.9 43 3.0 43 3.1 43 3.2
975 43 2.8 43 2.9 43 3.0 43 3.1
1000 43 2.6 43 2.7 43 2.8 43 2.9
U.S.A.
3001 to
4000
(914 to
1219)
775 42 3.2 42 3.3 42 3.4 42 3.5
800 43 3.6 43 3.8 42 3.2 42 3.3
825 43 3.4 43 3.5 43 3.7 43 3.8
850 43 3.2 43 3.3 43 3.4 43 3.6
875 43 3.0 43 3.1 43 3.3 43 3.4
900 43 2.9 43 3.0 43 3.1 43 3.2
925 43 2.7 43 2.8 43 2.9 43 3.0
950 43 2.6 43 2.7 43 2.8 43 2.8
U.S.A.
4001 to
5000
(1219 to
1524)
750 43 3.6 43 3.8 42 3.2 42 3.3
775 43 3.4 43 3.5 43 3.6 43 3.8
800 43 3.2 43 3.3 43 3.4 43 3.5
825 43 3.0 43 3.1 43 3.2 43 3.3
850 43 2.8 43 2.9 43 3.0 43 3.1
875 43 2.7 43 2.8 43 2.9 43 2.9
900 43 2.5 43 2.6 43 2.7 43 2.8
925 43 2.4 43 2.5 43 2.6 43 2.6
* Orifice numbers 43 are factory installed.
310AAV
