Bryant 355BAV User Manual

36
AIR CONDITIONING AIRFLOW* 060 & 080-14
MODEL
080-20 & 100
MODEL
120 MODEL
TONS (12,000 BTU/HR) (CFM)
1-1/2 525 (600) X
X
2 700 (800) X X X
2-1/2 875 (1000) X X X
3 1050 (1200) X X X
3-1/2 1225 (1400) X X X
4 1400 (1600) X X
5 1750 (2000) X
6 2100 (2100) X
X-INDICATES AN ALLOWABLE SELECTION.
A/C OR CF AIRFLOW SELECTION CHART
BASED ON 350 CFM/TON
MODEL
SIZE
060,
080-14
DEF 525
2
700 875 1050
1
1225 1225 1225
080-20, 100 DEF 700 875 1050 1225 1400 1750
1
1750
120 DEF 700 875
2
1050 1225 1400 1750
1
2100
1.DEFAULT A/C AIRFLOW WHEN A/C SWITCHES ARE IN OFF POSITION
2.DEFAULT CONT. FAN AIRFLOW WHEN CF SWITCHES ARE IN OFF POSITION
2
* Airflow shown in parentheses is airflow unit that the unit will deliver when setup switch SW1-5 is ON (selects 400 CFM/ton)
A06508
Fig. 39 -- A/C or CF Airflow Selection Chart Based on 350 and 400CFM/Ton
Table 9 – Furnace Setup Switch Description
SETUP SWITCH
NO.
SWITCH NAME
NORMAL
POSITION
DESCRIPTION OF USE
S W 1 --- 1 Status Code Recovery OFF
Turn ON to retrieve up to 7 stored status codes for troubleshooting
assistance when R thermostat lead is disconnected.
S W 1 --- 2 Adaptive Heat Mode OFF
Allows 2 --- stage operation with a single stage thermostat. Turn ON
when using 2 stage thermostat to allow Low Heat operation when
R to W/W1 closes and High Heat operation when R to W/W1 and
W2 close.
S W 1 --- 3 Low Heat Rise Adjust OFF
Turn ON to increase Low Heat airflow by 10 percent. This com-
pensates for increased return air temperature caused with bypass
humidifier.
S W 1 --- 4 Comfort/Efficiency Adjustment ON
Turn ON to decrease Low Heat airflow by 22 percent and High
Heat airflow 15 percent for maximum comfort.
S W 1 --- 5 CFM per ton adjust OFF Turn ON for 400 CFM per ton. Turn OFF for 350 CFM per ton.
S W 1 --- 6 Component Self--- Test OFF
Turn ON to initiate Component Self--- Test for troubleshooting as-
sistance when R thermostat lead is disconnected. Turn OFF when
Self--- Test is completed.
S W 1 --- 7 Blower OFF delay ON or OFF
Control blower Off Delay time. Used in conjunction with SW1---8.
See Table 10.
S W 1 --- 8 Blower OFF delay ON or OFF
Control blower Off Delay time. Used in conjunction with SW1---7.
See Table 10.
355BAV
