11
AIR
FLOW
OFF
ON
Plastic Caps
Yellow or black
Vent Drain
&Clamps
Trap Connection
“Clamp ears”
Pointed OUT
Preassemble &
insert into furnace
2 5 -- 2 4 -- 7 0
Single Pressure Switch Detail
Dual Pressure Switch
Tee Trap White PVC
(loose parts bag)
Cap and Clamp
Open End
Flexible tubing connector
3
/
16
(4.8mm) OD (Loose
Parts Bag)
EXHAUST
Alternate Orientation
Field
Supplied Tee
Cut Here
Cut at straight section
Leave room for clamp
Relief Tube Extension
Black Rubber
3
/
16
(4.8mm) ID
Cut to Fit (Loose Parts Bag)
AIR FLOW
Coupling & Clamps
(Optional)
Relief Tube Black Rubber
3
/
16
(4.8mm) ID
Drain Tube
Black Rubber
1
/
2
(12.7mm) ID
&Clamps
Drain Tube Corrugated
5
/
8
(15.9mm) ID & Clamps
Representative drawing only, some models may vary in appearance.
Remove KO before
mounting Trap
A07709
Fig. 11 -- Horizontal Left Through Top
359AAV
