28
ELECTRICAL DATA
UNIT
NOMINAL
V --- P H --- H Z
VOLTAGE
RANGE
COMPRESSOR OFM IFM IDM POWER SUPPLY
MIN MAX RLA LRA FLA FLA FLA MCA MOCP
577C--- ---A24040
208/230---1---60 197 253
13.5 58.3 0.7 4.1 0.65 21.7 30
577C--- ---A24060 13.5 58.3 0.7 4.1 1.65 21.7 30
577C--- ---A30040 12.8 64.0 0.7 4.1 0.65 20.8 30
577C--- ---A30060 12.8 64.0 0.7 4.1 1.65 20.8 30
577C--- ---A36060 14.1 77.0 1.2 6.0 1.65 24.8 35
577C--- ---A36090 14.1 77.0 1.2 6.0 0.52 24.8 35
577C--- ---A42060 17.9 112.0 1.2 6.0 1.65 29.6 40
577C--- ---A42090 17.9 112.0 1.2 6.0 0.65 29.6 40
577C--- ---A48090 21.8 117.0 1.2 7.6 0.65 36.1 50
577C--- ---A48115 21.8 117.0 1.2 7.6 1.65 36.1 50
577C--- ---A48130 21.8 117.0 1.2 7.6 0.52 36.1 50
577C--- ---A60090 26.4 134.0 1.2 7.6 0.65 41.8 60
577C--- ---A60115 26.4 134.0 1.2 7.6 1.65 41.8 60
577C--- ---A60130 26.4 134.0 1.2 7.6 0.52 41.8 60
577C--- ---A30040
208/230---3---60 197 253
8.3 58.0 0.7 4.1 0.65 15.2 20
577C--- ---A30060 8.3 58.0 0.7 4.1 1.65 15.2 20
577C--- ---A36060 9.0 71.0 1.2 6.0 1.65 18.5 25
577C--- ---A36090 9.0 71.0 1.2 6.0 0.52 18.5 25
577C--- ---A42060 13.5 88.0 1.2 6.0 1.65 24.1 35
577C--- ---A42090 13.5 88.0 1.2 6.0 0.65 24.1 35
577C--- ---A48090 13.7 83.1 1.2 7.6 0.65 25.9 35
577C--- ---A48115 13.7 83.1 1.2 7.6 1.65 25.9 35
577C--- ---A48130 13.7 83.1 1.2 7.6 0.52 25.9 35
577C--- ---A60090 16.0 110.0 1.2 7.6 0.65 28.8 40
577C--- ---A60115 16.0 110.0 1.2 7.6 1.65 28.8 40
577C--- ---A60130 16.0 110.0 1.2 7.6 0.52 28.8 40
577C--- ---A36060
4 6 0 --- 3 --- 6 0 414 506
5.6 38.0 0.5 3.0 0.70 10.5 15
577C--- ---A36090 5.6 38.0 0.5 3.0 0.30 10.5 15
577C--- ---A42060 6.0 44.0 0.5 3.0 0.70 11.0 15
577C--- ---A42090 6.0 44.0 0.5 3.0 0.33 11.0 15
577C--- ---A48090 6.2 41.0 0.5 3.8 0.33 12.1 15
577C--- ---A48115 6.2 41.0 0.5 3.8 0.70 12.1 15
577C--- ---A48130 6.2 41.0 0.5 3.8 0.30 12.1 15
577C--- ---A60090 7.8 52.0 0.5 3.8 0.33 14.1 20
577C--- ---A60115 7.8 52.0 0.5 3.8 0.70 14.1 20
577C--- ---A60130 7.8 52.0 0.5 3.8 0.30 14.1 20
228 =1v
229 =2v
227 =2v
LEGEND
FLA -- Full Load Amps
LRA -- Locked Rotor Amps
MCA -- Minimum Circuit Amps
MOCP -- Maximum Overcurrent Protection
RLA -- Rated Load Amps
NO TES:
1. In compliance with NEC (National Electrical Code) requirements
for multimotor and combination load equipment (refer to NE C
Articles 430 and 440), the overcurrent protective device for the
unit shall be Power Supply fuse. The CGA (Canadian Gas
Association) units may be fuse or circuit break er.
2. Minimum wire size is based on 60 C copper wire. I f other than
60 C wire is used, or if length exceeds wire length in table,
determine siz e from NEC..
3. Unbalanced 3-Phase Supply Voltage
Never operate a motor where a phase imbalance in supply volt-
age is greater than 2%.
Use the following formula to determine
the percentage of voltage imbalance.
% Voltage imbalance
max voltage deviation from average voltage
= 100 x
average voltage
EXAMPLE: Supply voltage is 230-3-60.
AB = 228 v
BC = 231 v
AC = 227 v
228 + 231 + 227
Average Voltage =
3
686
=
3
= 229
Determine maximum deviation from average voltage.
(AB) 229 -
(BC) 231 -
(AC) 229 -
Maximum deviation is 2 v.
Determine percent of voltage imbalance.
2
% Voltage Imbalance = 100 x
229
= 0.8%
This amount of phase imbalance is satisfactory as it is below the
maximum allowable 2%.
IMPORTANT: If the supply voltage phase imbalance is
more than 2%, contact your local electric utility company
immediately.
(R)
A06564
577C-- --A
