—14—
DETAILED COOLING CAPACITIES* Continued
See notes on page 18.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
594D030-E Outdoor Section With CC5A/CD5AA036 Indoor Section
875
72 32.5 16.1 2.58 31.2 15.6 2.97 29.8 15.1 3.42 28.3 14.5 3.9 26.3 13.8 5.04
67 29.7 20.4 2.59 28.5 19.9 2.99 27.2 19.3 3.43 25.7 18.7 3.9 23.6 17.9 5.11
62 27.1 24.5 2.62 26.0 24.0 3.01 24.8 23.3 3.46 23.4 22.6 4.0 21.4 21.4 5.01
57 26.1 26.1 2.64 25.1 25.1 3.04 24.1 24.1 3.47 23.0 23.0 4.0 21.4 21.4 5.03
1000
72 33.0 16.8 2.61 31.7 16.3 3.00 30.2 15.8 3.44 28.7 15.2 4.0 26.7 14.5 5.04
67 30.2 21.6 2.62 29.0 21.1 3.02 27.6 20.6 3.46 26.1 20.0 4.0 24.0 19.1 5.12
62 27.7 26.1 2.64 26.5 25.5 3.04 25.3 24.8 3.48 23.9 23.8 4.1 22.1 22.1 5.12
57 27.0 27.0 2.66 26.1 26.1 3.06 25.0 25.0 3.50 23.8 23.8 4.0 22.2 22.2 5.07
1125
72 33.4 17.4 2.64 32.0 17.0 3.03 30.6 16.5 3.52 29.0 15.9 4.0 27.0 15.2 5.07
67 30.6 22.8 2.66 29.4 22.3 3.05 28.0 21.7 3.54 26.4 21.1 4.1 24.3 20.3 5.15
62 28.2 27.6 2.67 27.0 26.8 3.07 25.8 25.8 3.56 24.5 24.5 4.1 22.6 22.6 5.34
57 27.9 27.9 2.68 26.9 26.9 3.08 25.8 25.8 3.58 24.6 24.6 4.1 22.8 22.8 5.18
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AA 030 0.97 1.00 FK4CNF 001 1.01 0.96
036 1.00 1.00 002 1.01 0.96
CC5A/CD5AW 030 0.97 1.00 003 1.02 0.92
CD5AW 036 1.00 1.00
COILS + 333(B,J)AV036060 VARIABLE SPEED FURNACE
CE3AA 030 0.98 1.00 CC5A/CD5AA 036 1.01 0.92
036 0.99 1.00 CE3AA 036 1.00 0.93
CF5AA 036 1.00 1.00 CK5A/CK5BA 036 1.01 0.93
CK3BA 030 0.97 1.00
COILS + 333(B,J)AV048080 VARIABLE SPEED FURNACE
036 1.00 1.00 CC5A/CD5AA 036 1.01 0.92
CK5A/CK5BA 030 0.97 1.00 CE3AA 036 1.00 0.93
036 1.00 1.00 CK5A/CK5BA 036 1.01 0.92
CK5A/CK5BW 030 0.97 1.00
COILS + 355MAV042040 VARIABLE SPEED FURNACE
036 1.00 1.00 CC5A/CD5AA 036 1.01 0.94
F(A,B)4AN(F,C) 030 0.97 0.99 CK5A/CK5BA 036 1.01 0.94
036 0.99 1.01
COILS + 355MAV042060 VARIABLE SPEED FURNACE
FC4BNF 030 0.97 0.99 CC5A/CD5AA 036 1.01 0.94
036 0.99 1.01 CK5A/CK5BA 036 1.01 0.96
FF1(B,C,D)NA 030 0.98 1.00
COILS + 355MAV042080 VARIABLE SPEED FURNACE
FG3AAA 036 0.99 1.00 CC5A/CD5AA 036 1.01 0.94
— — — CK5A/CK5BA 036 1.01 0.94
