—15—
DETAILED COOLING CAPACITIES* Continued
See notes on page 18.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
594D036-E Outdoor Section With CC5A/CD5AA042 Indoor Section
1050
72 39.1 19.4 3.13 37.5 18.8 3.47 35.9 18.3 3.84 34.3 17.7 4.2 32.6 17.7 4.69
67 35.9 24.7 3.10 34.5 24.1 3.44 33.0 23.5 3.81 31.4 22.9 4.2 29.8 22.2 4.64
62 32.9 29.8 3.08 31.6 29.2 3.42 30.2 28.5 3.79 28.8 27.7 4.1 27.3 26.9 4.61
57 31.6 31.6 3.08 30.6 30.6 3.41 29.5 29.5 3.78 28.4 28.4 4.1 27.1 27.1 4.57
1200
72 39.6 20.2 3.19 38.1 19.7 3.53 36.4 19.1 3.91 34.7 18.5 4.3 32.9 17.9 4.75
67 36.5 26.2 3.16 35.0 25.6 3.50 33.5 25.0 3.87 31.8 24.4 4.2 30.2 23.7 4.70
62 33.5 31.8 3.14 32.2 31.0 3.48 30.8 30.2 3.84 29.4 29.3 4.2 28.0 28.0 4.66
57 32.8 32.8 3.14 31.7 31.7 3.48 30.5 30.5 3.85 29.3 29.3 4.2 27.9 27.9 4.64
1350
72 40.0 21.0 3.25 38.4 20.5 3.59 36.7 19.9 3.96 34.9 19.3 4.3 33.1 18.6 4.80
67 36.9 27.6 3.22 35.3 27.0 3.56 33.8 26.4 3.93 32.1 25.8 4.3 30.4 25.1 4.76
62 34.0 33.4 3.20 32.7 32.5 3.53 31.3 31.3 3.90 30.1 30.1 4.3 28.7 28.7 4.73
57 33.7 33.7 3.20 32.6 32.6 3.54 31.3 31.3 3.91 30.1 30.1 4.3 28.6 28.6 4.71
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AA 036 1.00 1.00 CE3AA 042 0.99 0.95
042 1.00 1.00 CK5A/CK5BA 042 0.99 0.94
CC5A/CD5AW 042 0.99 1.00
COILS + 333(B,J)AV048080 VARIABLE SPEED FURNACE
CD5AW 036 1.00 1.00 CC5A/CD5AA 042 0.99 0.94
CE3AA 036 0.98 1.00 CE3AA 042 0.99 0.95
042 1.00 1.00 CK5A/CK5BA 042 0.99 0.94
CF5AA 036 1.00 1.00
COILS + 333(B,J)AV060100 VARIABLE SPEED FURNACE
CG5AA 036 1.00 1.00 CC5A/CD5AA 042 0.99 0.94
CK3BA 036 1.00 1.00 CE3AA 042 0.99 0.95
042 1.00 1.00 CK5A/CK5BA 042 0.99 0.94
CK5A/CK5BA 036 1.00 1.00
COILS + 333(B,J)AV060120 VARIABLE SPEED FURNACE
042 1.00 1.00 CC5A/CD5AA 042 0.99 0.94
CK5A/CK5BW 036 1.00 1.00 CE3AA 042 0.99 0.95
042 0.99 1.00 CK5A/CK5BA 042 0.99 0.94
F(A,B)4AN(F,C) 036 0.98 1.02
COILS + 355MAV042040 VARIABLE SPEED FURNACE
F(A,B)4AN(F,B,C) 042 1.00 1.01 CC5A/CD5AA 042 0.99 0.93
FC4BN(F,B) 042 1.00 1.01 CK5A/CK5BA 042 0.99 0.93
FC4BNB 054 1.05 1.00
COILS + 355MAV042060 VARIABLE SPEED FURNACE
FC4BNF 036 0.98 1.02 CC5A/CD5AA 042 0.99 0.93
FG3AAA 036 0.98 1.00 CK5A/CK5BA 042 0.99 0.93
FK4CNB 006 1.03 0.93
COILS + 355MAV042080 VARIABLE SPEED FURNACE
FK4CNF 001 0.99 0.98 CC5A/CD5AA 042 0.99 0.93
002 0.99 0.98 CK5A/CK5BA 042 0.99 0.93
003 1.00 0.93
COILS + 355MAV060100 VARIABLE SPEED FURNACE
005 1.03 0.94 CC5A/CD5AA 042 0.99 0.93
COILS + 333(B,J)AV036060 VARIABLE SPEED FURNACE CK5A/CK5BA 042 0.99 0.93
CC5A/CD5AA 042 0.99 0.94 — — —
