—13—
COMBINATION RATINGS Continued
* Tested combination.
† In most cases, only 1 method should be used to achieve TDR function. Using more than 1 method in a system may cause degradation in performance.
Use either the accessory Time-Delay Relay KAATD0101TDR or a furnace equipped with TDR. All Bryant furnaces are equipped with TDR except for
the 394HAD.
‡ Based on computer simulation. Requires hard shutoff TXV.
EER — Energy Efficiency Ratio
LLS — Liquid-Line Solenoid Valve
SEER — Seasonal Energy Efficiency Ratio
TDR — Time-Delay Relay
TXV — Thermostatic Expansion Valve
NOTES: 1. Ratings are net values reflecting the effects of circulating fan motor heat. Supplemental electric heat is not included.
2. Tested outdoor/indoor combinations have been tested in accordance with DOE test procedures for electric air conditioners. Ratings for other com-
binations are determined under DOE computer simulation procedures.
3. Determine actual CFM values obtainable for your system by referring to fan performance data in fan coil or furnace coil literature.
4. Do not apply with capillary tube coils as performance and reliability are significantly affected.
UNIT
SIZE-
SERIES
INDOOR
SECTION
TOTAL CAP.
BTUH
FACTORY-
SUPPLIED
ENHANCE-
MENT
SEER
EER
STANDARD
RATING
BRYANT GAS
FURNACE OR
ACCESSORY
TDR†
ACCESSORY
TXV‡ LLS
048-G, F
COILS + 355MAV060100 VARIABLE SPEED FURNACE
CC5A/CD5AC048 46,000 TDR 12.00 — 12.00 — 10.65
CC5A/CD5AW060 48,000 TDR 12.80 — 12.80 — 11.25
CD5AA048 47,000 TDR 12.50 — 12.50 — 10.90
CK3BA048 47,000 TDR 12.50 — 12.50 — 10.95
CK3BA060 47,000 TDR 12.50 — 12.50 — 11.20
CK5A/CK5BA048 47,000 TDR 12.50 — 12.50 — 10.95
CK5A/CK5BX060 48,000 TDR 12.80 — 12.80 — 11.45
COILS + 355MAV060120 VARIABLE SPEED FURNACE
CC5A/CD5AA060 47,000 TDR 12.50 — 12.50 — 11.00
CC5A/CD5AW048 47,000 TDR 12.50 — 12.50 — 10.90
CC5A/CD5AW060 48,000 TDR 13.00 — 13.00 — 11.30
CK5A/CK5BA060 47,000 TDR 12.50 — 12.50 — 11.25
CK5A/CK5BW048 47,000 TDR 12.50 — 12.50 — 11.00
CK5A/CK5BX060 48,000 TDR 13.00 — 13.00 — 11.50
060-F
CC5A/CD5AW060* 57,000 NONE — 12.00 12.00 12.00 10.30
CC5A/CD5AA060 55,000 NONE — 12.00 12.00 12.00 10.20
CE3AA060 57,000 NONE — 12.00 12.00 12.00 10.40
CK3BA060 55,000 NONE — 12.00 12.00 12.00 10.45
CK5A/CK5BA060 55,000 NONE — 12.00 12.00 12.00 10.35
CK5A/CK5BN060 55,000 NONE — 12.00 12.00 12.00 10.55
CK5A/CK5BX060 57,000 NONE — 12.00 12.00 12.00 10.45
F(A,B)4AN(F,B)060 57,000 TDR 11.50 — 11.50 — 9.95
FB4ANB070 58,000 TDR 12.00 — 12.00 — 10.40
FC4BNB070 58,000 TDR & TXV 12.00 — — — 10.40
FC4BN(F,B)060 57,000 TDR & TXV 11.50 — — — 9.95
FG3AAA060 57,000 NONE — 12.00 12.00 12.00 10.30
FK4BNB006 58,000 TDR & TXV 12.50 — — — 10.65
FK4CNB006 58,000 TDR & TXV 12.50 — — — 10.65
COILS + 333(B,J)AV060100 VARIABLE SPEED FURNACE
CC5A/CD5AW060 57,000 TDR 12.50 — 12.50 — 10.75
CK3BA060 55,500 TDR 12.50 — 12.50 — 10.90
CK5A/CK5BA060 55,500 TDR 12.00 — 12.00 — 10.60
CK5A/CK5BX060 56,500 TDR 12.50 — 12.50 — 10.90
COILS + 333(B,J)AV060120 VARIABLE SPEED FURNACE
CK3BA060 55,000 TDR 12.50 — 12.50 — 10.80
CK5A/CK5BA060 55,500 TDR 12.00 — 12.00 — 10.45
CK5A/CK5BX060 56,500 TDR 12.50 — 12.50 — 10.80
