A. UNIT CHARGE
Factory charge and charging method are shown on unit informa-
tion plate. Puron® refrigerant cylinders contain a dip tube
which allows liquid refrigerant to flow from cylinder in
upright position. Charge Puron units with cylinder in upright
position and a commercial type metering device in manifold hose.
Charge refrigerant into suction line.
NOTE: Unit is to be charged in high capacity only. Charging in
low capacity may cause compressor chattering and possible
damage to the compressor.
NOTE: If subcooling charging conditions are not favorable,
charge must be weighed in accordance with unit rating plate ± 0.6
oz/ft of 3/8-in. liquid line above or below 15 ft respectively.
EXAMPLE: To calculate additional charge required for a 25 ft line
set: 25 ft - 15 ft = 10 ft x 0.6 oz/ft=6ozofadditional charge.
B. COOLING ONLY PROCEDURE
Units installed with cooling mode TXV require charging by the
subcooling method. Units should be charged in high speed
(capacity) only.
TABLE 3—WIRING DIAGRAM REFERENCE
INDOOR PRODUCT THERMOSTAT CONTROLS
DIAGRAM LETTER
IN FIG. 9
Standard Fan Coil
Bryant Programmable (Model 2S) Latent Capacity A
Bryant Non-Programmable (Model 2S) Latent Capacity B
Bryant Thermidistat™ Control Humidifier and Outdoor Sensor C
Other Brand Models Latent Capacity D
FK4C or FV4A Fan Coil
Bryant Programmable (Model 2S) — E
Bryant Non-Programmable (Model 2S) — F
Bryant Thermidistat™ Control Humidifier and Outdoor Sensor G
Other Brand Models — H
Single-Stage Furnace
Bryant Programmable (Model 2S) Latent Capacity J
Bryant Non-Programmable (Model 2S) Latent Capacity K
Bryant Thermidistat™ Control Humidifier and Outdoor Sensor L
Other Brand Models Latent Capacity M
Two-Stage Furnace with PSC Blower Motor
Bryant Programmable (Model 2S) Latent Capacity N
Bryant Non-Programmable (Model 2S) Latent Capacity P
Bryant Thermidistat™ Control Humidifier and Outdoor Sensor Q
Other Brand Models Latent Capacity R
Two-Stage Furnace with ICM Blower Motor
Bryant Programmable (Model 2S) — S
Bryant Non-Programmable (Model 2S) — T
Other Brand Models — U
Variable-Speed 80 percent Non-Condensing Furnace Bryant Thermidistat™ Control Humidifier and Outdoor Sensor V
Variable-Speed Condensing Furnace Bryant Thermidistat™ Control Humidifier and Outdoor Sensor W
TABLE 4—AIRFLOW SELECTION FOR 333AAV FURNACES (CFM)
598B
UNIT
SIZE
FURNACE
MODEL/HEATING
SIZE
FURNACE AIRFLOW SELECTION BOARD SETTINGS
AC/HP
Jumper
Position
Cool Size
Jumper
Position
Cool CFM Per Ton Jumper Position
400 350 315
High Low High Low High Low
024 060 AC M-LO 865 510 735 500 660 500
036
060 AC HI 1260 780 1100 680 990 585
080 AC M-LO 1260 790 1100 700 990 625
100 AC LO 1260 780 1090 775 990 700
120 AC LO 1195 865 1085 785 985 785
048
080 AC HI 1635 1040 1470 915 1325 820
100 AC M-HI 1680 1040 1465 915 1325 820
120 AC M-HI 1650 1070 1465 975 1315 930
060
100 AC HI 1085 1300 1840 1150 1655 1025
120 AC HI 2110 1300 1865 1140 1640 1080
TABLE 5—AIRFLOW SELECTION FOR 355MAV FURNACES (CFM)
598B
UNIT
SIZE
HIGH-SPEED
A/C SETUP
SWITCH POSITION
FURNACE MODEL/HEATING SIZE
LOW-SPEED
CF SETUP
SWITCH POSITION
040 60 80 100
A/C-11 A/C-2 A/C-3 High Low High Low High Low High Low CF-1 CF-2 CF-3
024 OFF ON OFF 800 565 800 515 —— — —OFF OFF OFF
036 OFF OFF ON ——1200 800 1200 800 1200 800 OFF ON OFF
048 OFF ON ON ——————1600 1000 ON ON OFF
060 OFF ON ON ——————1600* 1000 ON ON OFF
* Efficiency rating obtained at 1600 CFM. If 2000 CFM is desired, adjust airflow per 355MAV Installation Instructions.
