—16—
PERFORMANCE DATA (CONT)–STANDARD ECM INDOOR MOTOR
COOLING EXTENDED PERFORMANCE TABLE
HEATING EXTENDED PERFORMANCE TABLE -10–20
HEATING EXTENDED PERFORMANCE TABLE 30–60
*At 75°F entering dry bulb—Tennessee Valley Authority [TVA] rating conditions; all others at 80°F entering dry bulb.
See Legend and Notes on page 17.
604B060 COOLING PERFORMANCE TABLE
Temp (F)
Outdoor Air
Entering
Condenser
Evaporator Air—CFM/BF
1500/0.004 1750/0.007 2000/0.01
Evaporator Air — Ewb (F)
62 63* 67 72 62 63* 67 72 62 63* 67 72
75
TC 57.2 58.2 62.4 68.1 58.8 59.7 64.0 69.8 60.0 60.8 64.9 70.8
SHC 49.4 47.9 41.6 33.8 53.6 51.8 44.5 35.4 57.6 55.4 47.1 36.8
kW 4.1 4.1 4.2 4.2 4.2 4.3 4.3 4.4 4.4 4.4 4.5 4.6
85
TC 54.7 55.6 59.7 65.2 56.2 57.0 61.1 66.6 57.4 58.1 61.9 67.4
SHC 48.2 46.7 40.4 32.6 52.4 50.5 43.2 34.2 56.3 54.2 45.8 35.6
kW 4.5 4.5 4.6 4.7 4.7 4.7 4.8 4.9 4.8 4.9 5.0 5.0
95
TC 52.2 53.0 56.9 62.0 53.5 54.3 58.0 63.2 55.0 55.3 58.7 64.1
SHC 47.0 45.4 39.2 31.4 51.1 49.2 41.9 32.9 55.0 52.9 44.5 34.4
kW 5.0 5.0 5.1 5.2 5.1 5.2 5.3 5.3 5.2 5.3 5.5 5.5
105
TC 49.4 50.2 53.8 58.7 50.7 51.4 54.8 59.6 52.5 52.4 55.4 60.2
SHC 45.7 44.1 37.9 30.1 49.8 47.9 40.6 31.6 52.5 51.6 43.2 33.0
kW 5.5 5.6 5.6 5.7 5.7 5.7 5.8 5.9 5.8 5.8 6.0 6.1
115
TC 46.5 47.2 50.5 55.0 48.1 48.3 51.3 56.8 49.7 49.7 51.8 57.0
SHC 44.3 42.7 36.4 28.7 48.1 46.6 39.2 30.6 49.7 49.7 41.8 31.7
kW 6.1 6.2 6.2 6.3 6.2 6.3 6.4 6.4 6.4 6.4 6.6 6.6
125
TC 43.3 43.9 46.7 52.2 45.2 45.1 47.4 52.5 46.4 46.4 47.9 52.2
SHC 42.8 41.2 34.9 27.8 45.2 45.1 37.6 28.9 46.4 46.4 40.2 29.7
kW 6.7 6.8 6.8 6.8 6.8 6.9 7.0 7.0 7.0 7.0 7.2 7.2
604B060
Return
Air (F db)
CFM (Standard Air)
Air Temperature Entering Outdoor Coil (F db at 70% rh)
-10 0 10 17 20
60
1500
TC 17.89
16.55 22.37 20.58 27.39 25.14 27.90 25.44 33.30 30.20
kW 3.14 3.33 3.56 3.71 3.76
1750
TC 18.44
17.06 22.91 21.08 28.07 25.77 32.32 29.47 34.25 31.06
kW 3.23 3.39 3.60 3.74 3.78
2000
TC 19.03
17.60 23.49 21.62 28.75 26.38 33.08 30.16 35.08 31.81
kW 3.36 3.50 3.70 3.82 3.86
70
1500
TC 16.20
14.98 21.25 19.55 26.32 24.16 30.28 27.61 32.03 29.05
kW 3.36 3.66 3.89 4.09 4.14
1750
TC 16.82
15.56 21.85 20.11 26.96 24.74 31.00 28.26 32.81 29.76
kW 3.48 3.74 3.96 4.12 4.16
2000
TC 17.49
16.17 22.50 20.71 27.85 25.56 31.74 28.94 33.60 30.47
kW 3.62 3.86 4.07 4.21 4.25
80
1500
TC 13.77
12.73 19.62 18.05 25.11 23.05 28.93 26.37 30.64 27.79
kW 3.50 3.94 4.24 4.47 4.54
1750
TC 14.42
13.34 20.32 18.69 25.79 23.67 29.68 27.06 31.43 28.50
kW 3.63 4.04 4.31 4.52 4.57
2000
TC 15.10
13.96 21.01 19.33 26.48 24.31 30.45 27.76 32.22 29.22
kW 3.79 4.19 4.42 4.62 4.67
604B060
Return
Air (F db)
CFM (Standard Air)
Air Temperature Entering Outdoor Coil (F db at 70% rh)
30 40 47 50 60
60
1500
TC 40.88
35.82 49.46 49.46 54.82 54.82 58.83 58.83 63.53 63.53
kW 3.98 4.26 4.47 4.53 4.71
1750
TC 42.02
36.82 50.89 50.89 56.64 56.64 58.34 58.34 61.76 61.76
kW 3.97 4.25 4.33 4.38 4.51
2000
TC 43.05
37.72 52.52 52.52 56.01 56.01 57.04 57.04 60.19 60.19
kW 4.03 4.26 4.30 4.34 4.46
70
1500
TC 39.08
34.24 47.32 47.32 52.27 52.27 53.85 53.85 58.08 58.08
kW 4.36 4.64 4.80 4.86 4.99
1750
TC 40.15
35.18 48.73 48.73 56.00 56.00 58.71 58.71 66.11 66.11
kW 4.35 4.60 4.82 4.88 5.08
2000
TC 41.14
36.05 49.89 49.89 56.89 56.89 58.64 58.64 62.11 62.11
kW 4.40 4.65 4.79 4.84 4.97
80
1500
TC 37.15
32.55 39.76 39.76 41.79 41.79 42.85 42.85 46.59 46.59
kW 4.77 4.80 4.82 4.87 5.01
1750
TC 38.40
33.64 45.36 45.36 47.19 47.19 48.68 48.68 52.98 52.98
kW 4.78 4.95 4.96 5.01 5.15
2000
TC 39.35
34.48 47.88 47.88 52.12 52.12 53.40 53.40 59.14 59.14
kW 4.84 5.06 5.13 5.16 5.32
