Bryant 604B - ELECTRICAL DATA

—22—
ELECTRICAL DATA
See Legend and Notes on p. 23
UNIT 604B
SIZE
V-PH-HZ
VOLTAGE
RANGE
COMPRESSOR
ODFM
FLA
IDFM
FLA
ELECTRIC HEAT SINGLE POINT POWER SUPPLY
Min Max RLA LRA Nominal kW* FLA UNIT MCA MAX FUSE OR CKT BKR MOCP
024 208/230–1–60 187 253 13.5 61.0 0.9 4.3
-/-
3.8/5.0
5.4/7.2
7.5/10.0
-/-
18.1/20.8
26/30
36.1/41.7
22.1/22.1
44.6/48.1
54.6/59.6
67.2/74.2
30/30
60/60
—
—
—
—
70/70
80/80
030 208/230–1–60 187 253 15.9 73.0 0.9 4.3
-/-
3.8/5.0
5.4/7.2
7.5/10.0
11.3/15.0
-/-
18.1/20.8
26/30
36.1/41.7
54.2/62.5
25.1/25.1
47.6/51.1
57.6/62.6
70.2/77.2
92.8/103.2
30/30
—
—
—
—
—
60/70
70/80
80/90
100/110
036
208/230–1–60 187 253 16.9 83.0 0.9 6.8
-/-
3.8/5.0
5.4/7.2
7.5/10.0
11.3/15.0
-/-
18.1/20.8
26/30
36.1/41.7
54.2/62.5
28.8/28.8
51.4/54.9
61.3/66.3
74.0/80.9
96.5/107
35/35
—
—
—
—
—
70/70
80/80
90/90
100/110
208/230–3–60 187 253 12.2 77.0 1.6 6.8
-/-
3.8/5.0
7.5/10.0
11.3/15.0
-/-
10.4/12.0
20.8/24.1
31.3/36.1
23.7/23.7
36.7/38.7
49.7/53.7
62.7/68.8
30/30
50/50
60/60
—
—
—
—
70/80
042
208/230–1–60 187 253 22.4 105.0 0.9 6.8
-/-
3.8/5.0
5.4/7.2
7.5/10.0
11.3/15.0
15.0/20.0
-/-
18.1/20.8
26/30
36.1/41.7
54.2/62.5
72.2/83.3
35.7/35.7
58.3/61.7
68.2/73.2
80.8/87.8
103.4/113.8
126.0/139.9
45/45
—
—
—
—
—
—
80/80
90/90
100/100
125/125
150/150
208/230–3–60 187 253 15.4 88.0 0.9 6.8
-/-
3.8/5.0
7.5/10.0
11.3/15.0
15.0/20.0
-/-
10.4/12.0
20.8/24.1
31.3/36.1
41.6/48.0
27.0/27.0
40.0/42.0
53.0/57.0
66.0/72.1
78.9/86.9
35/35
60/60
—
—
—
—
—
70/70
80/80
90/100
048
208/230–1–60 187 253 21.3 109.0 1.6 6.8
-/-
3.8/5.0
5.4/7.2
7.5/10.0
11.3/15.0
15.0/20.0
-/-
18.1/20.8
26/30
36.1/41.7
54.2/62.5
72.2/83.3
35.0/35.0
57.6/61.1
67.5/72.5
80.2/87.1
102.7/113.2
125.3/139.2
45/45
—
—
—
—
—
—
80/80
90/90
100/100
125/125
150/150
208/230–3–60 187 253 14.7 91.0 1.6 6.8
-/-
3.8/5.0
7.5/10.0
11.3/15.0
15.0/20.0
-/-
10.4/12.0
20.8/24.1
31.3/36.1
41.6/48.0
26.8/26.8
39.8/41.8
52.8/56.8
65.9/71.9
78.7/86.7
35/35
60/60
—
—
—
—
—
70/70
80/80
90/90
060
208/230–1–60 187 253 26.9 145.0 1.5 9.1
-/-
3.8/5.0
5.4/7.2
7.5/10.0
11.3/15.0
15.0/20.0
-/-
18.1/20.8
26/30
36.1/41.7
54.2/62.5
72.2/83.3
44.2/44.2
66.8/70.3
76.7/81.7
89.4/96.3
111.9/122.4
134.5/148.4
60/60
—
—
—
—
—
—
90/100
100/110
110/125
150/150
150/175
208/230–3–60 187 253 17.6 123.0 1.5 9.1
-/-
3.8/5.0
7.5/10.0
11.3/15.0
15.0/20.0
-/-
10.4/12.0
20.8/24.1
31.3/36.1
41.6/48.0
32.6/32.6
58.7/62.7
58.7/62.7
71.7/77.7
84.6/92.6
40/40
60/60
—
—
—
—
—
70/70
80/80
90/90
