810SA/811SA: Installation, Start–Up, Operating and Service and Maintenance Instructions
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
12
Table 4 – Air Delivery - CFM (With Filter)*
Furnace
Wire Lead
Color
Function
Test Airflow Delivery @ Various External Static Pressures
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
36045E14
Gray Cooling. Do not use for heating. 1230 1190 1155 1120 1080 1045 1010 975 935 895
Yellow Alt Cooling or alt Heating 980 945 920 890 855 815 770 735 690 645
Orange Alt Cooling or alt Heating 770 720 685 640 600 560 520 475 430 385
Blue Heating or alt Cooling 710 660 620 580 540 490 455 415 375 335
Red Alt Cooling. Do not use for heating. 600 540 500 455 415 385 345 305 235 -
36045E17
Gray Cooling. Do not use for heating. 1370 1335 1295 1255 1215 1175 1135 1095 1055 1020
Yellow Alt Cooling or alt Heating 1130 1085 1040 995 955 910 865 825 780 730
Orange Alt Cooling or alt Heating 930 885 835 795 745 700 655 600 545 495
Blue Heating or alt Cooling 760 720 670 625 580 515 460 410 355 300
Red Alt Cooling. Do not use for heating. 610 500 445 375 320 260 200 135 - -
36070E14
Gray Cooling. Do not use for heating. 1205 1170 1143 1105 1070 1035 1000 960 925 885
Blue Heating or alt Cooling 1095 1060 1030 995 960 925 885 840 800 735
Yellow Alt Cooling or alt Heating 920 880 845 805 765 730 685 620 560 510
Orange Alt Cooling. Do not use for heating. 715 650 610 575 520 465 410 380 305 245
Red Alt Cooling. Do not use for heating. 635 490 445 375 315 270 205 230 190 140
36070E17
Gray Cooling. Do not use for heating. 1185 1140 1095 1055 1005 960 915 865 820 780
Yellow Alt Cooling or alt Heating 1000 940 895 850 800 750 695 650 600 555
Blue Heating or alt Cooling 990 935 895 845 790 740 690 640 590 535
Orange Alt Cooling or alt Heating 855 775 720 660 605 560 495 435 385 335
Red Alt Cooling. Do not use for heating. 860 685 515 445 385 340 275 205 - -
48070E17
Gray Cooling. Do not use for heating. 1650 1615 1580 1545 1515 1480 1445 1415 1380 1350
Yellow Alt Cooling. Do not use for heating 1405 1365 1325 1285 1250 1215 1175 1140 1100 1065
Orange Alt Cooling or alt Heating 1255 1215 1175 1130 1090 1090 1010 970 930 895
Blue Heating or alt Cooling 1185 1140 1095 1050 1005 1005 920 880 840 800
Red Alt Cooling. Do not use for heating. 1100 1050 1005 960 915 915 825 785 740 700
48070E21
Gray Cooling. Do not use for heating. 1735 1685 1640 1595 1545 1495 1450 1405 1360 1310
Yellow Alt Cooling or alt Heating 1480 1435 1395 1340 1290 1240 1190 1135 1085 1030
Blue Heating or alt Cooling 1315 1275 1225 1180 1135 1085 1030 975 915 860
Orange Alt Cooling or alt Heating 1135 1080 1030 985 935 885 835 770 705 645
Red Alt Cooling. Do not use for heating. 980 930 875 820 775 715 665 595 530 455
42090E17
Gray Cooling. Do not use for heating. 1355 1320 1285 1245 1210 1165 1125 1080 1025 815
Yellow Alt Cooling or alt Heating 1295 1255
1220 1185 1140 1100 1055 1005 955 815
Blue Heating or alt Cooling 1220 1185 1150 1105 1065 1025 975 915 840 740
Orange Alt Cooling or alt Heating 1030 985 940 900 845 790 715 655 590 535
Red Alt Cooling. Do not use for heating. 945 905 855 800 750 670 600 540 490 435
48090E21
Gray Cooling. Do not use for heating. 1625 1580 1535 1490 1445 1395 1340 1260 1135 995
Yellow Alt Cooling or alt Heating 1425 1380 1335 1290 1235 1185 1125 1075 1020 640
Blue Heating or alt Cooling 1440 1395 1350 1305 1255 1200 1145 1090 1040 950
Orange Alt Cooling or alt Heating 1260 1210 1160 1105 1050 990 935 880 820 755
Red Alt Cooling. Do not use for heating. 1095 1040 980 905 845 780 720 650 585 520
60090E21
Gray Cooling. Do not use for heating. 2180 2130 2080 2030 1980 1925 1870 1805 1745 1680
Yellow Alt Cooling or alt Heating 1900 1845 1795 1740 1685 1635 1570 1500 1435 1375
Blue Heating or alt Cooling 1685 1620 1565 1505 1455 1385 1320 1260 1200 1140
Orange Alt Cooling or alt Heating 1390 1315 1240 1175 1095 1030 970 900 825 760
Red Alt Cooling. Do not use for heating. 1240 1155 1075 990 915 835 765 690 615 555
60090E24
Gray Cooling. Do not use for heating. 2190 2135 2075 2015 1960 1900 1835 1775 1705 1630
Yellow Alt Cooling or alt Heating 1870 1810 1745 1685 1625 1565 1495 1420 1345 1280
Blue Heating or alt Cooling 1580 1510 1445 1385 1320 1240 1175 1115 1050 970
Orange Alt Cooling or alt Heating 1305 1220 1160 1075 1000 930 865 770 690 610
Red Alt Cooling. Do not use for heating. 1210 1075 1000 915 845 765 675 595 515 425
60110E21
Gray Cooling. Do not use for heating. 2255 2205 2150 2100 2040 1985 1920 1835 1735 1615
Blue Heating or alt Cooling 1945 1890 1830 1770 1715 1655 1600 1545 1480 1430
Yellow Alt Cooling or alt Heating 1600 1525 1465 1400 1335 1275 1210 1150 1080 1015
Orange Alt Cooling. Do not use for heating. 1420 1340 1280 1200 1140 1065 1005 925 865 790
Red Alt Cooling. Do not use for heating. 1280 1205 1140 1055 990 910 840 760 695 630
