ITEM PART NO. QTY. DESCRIPTION
1098671 1 ASSY ROTOR 10KW
098681 1 ASSY ROTOR 15KW
098675 1 ASSY ROTOR 20KW
098936 1 ASSY ROTOR 25KW
2 0A5336A 1 HOUSING BLOWER
3 0A1659 1 SCREEN AIR OUTLET
4 071912 4 SCREW PPHM M5-0.8 X 8 SS
5049226 4 WASHER LOCK M5
6 051713 4 WASHER FLAT M5
7 022129 4 WASHER LOCK M8-5/16
8098672 1 ASSY STATOR 10KW A
098673 1 ASSY STATOR 10KW D
098674 1 ASSY STATOR 10KW GJK
098682 1 ASSY STATOR 15KW 1PH A
098683 1 ASSY STATOR 15KW 3PH D
098684 1 ASSY STATOR 15KW 1PH GJK
098676 1 ASSY STATOR 20KW 1PH A
098677 1 ASSY STATOR 20KW 1PH D
098678 1 ASSY STATOR 20KW 1PH GJK
097620 1 ASSY STATOR 25KW 1PH A
098937 1 ASSY STATOR 25KW 1PH D
097621 1 ASSY STATOR 25KW 3PH D
9 0A5382 1 BEARING CARRIER REAR
10 075591 1 ASSY HOLDER BRUSH
11 075476 4 SCREW PPHM M4-0.7 X 16
12 0A5601 1 COVER REAR BEARING CARRIER
13 075554B 4 BOLT STATOR X 16" LG
14 0A9375 4 SCREW RHM #10-24 X 2
15 022152 4 WASHER LOCK #10
16 097146 1 FAN & RING GEAR ASSEM.
17 042558 1 KEY SQ 3/8 X 1 STEEL
18 0A5061 1 SPACER-FLEX PLATE
19 0A4989 1 PLATE, FLEX
20 053557 1 SCREW HHC M12-1.75 X 40 G8.8
21 051769 6 WASHER LOCK M12
22 049541 4 SCREW HHC M10-1.5 X 35 G8.8
23 046526 4 WASHER LOCK M10
24 045772 4 NUT HEX M10-1.5 G8 YEL CHR
26 * 087599 1 PLUG PLASTIC 3/8 NPT
27 077043E 1 FLEX CONDUIT 1" BLACK (NOT SHOWN)
28 022131 4 WASHER FLAT 3/8-M10 ZINC
29 072578 1 SPACER ROTOR SHAFT
30 0A7043 5 SCREW HHC M12-1.25 X 25 G8.8
31 049808 5 WASHER FLAT M12
32 058589 1 DECAL WARN ENG START
33 023365 4 WASHER SHAKEPROOF INT #8
35 0A8830 4 WASHER FLAT .34 ID X .75 OD
36 072080 1 DECAL, DANGER STANBY UNITS
* USED ON PRE-PACKAGED UNITS ONLY
Section 9 - Exploded Views and Parts
Bryant Liquid-cooled 15 kW Generators
Alternator — Drawing No. 0A9348-F
