—4—
A98068
UNIT SERIES
A C D SHIPPING WEIGHT
In. mm In. mm In. mm Lb. Kg.
CC5AXA018014 A 12-5/8 320.7 10-9/16 268.3 5/8 15.88 15 6.8
CC5AXA024014 A 12-5/8 320.7 12-11/16 322.2 5/8 15.88 17 7.7
CC5AXW024017 A 15-15/16 404.8 14-3/4 374.6 3/4 19.05 22 10.0
CC5AXA030014 A 12-5/8 320.7 15-1/8 384.2 3/4 19.05 20 9.1
CC5AXW030017 A 15-15/16 404.8 14-3/4 374.6 3/4 19.05 22 10.0
CC5AXA036017 A 15-15/16 404.8 18-1/2 469.9 3/4 19.05 24 10.9
CC5AXW036021 A 19-3/8 492.1 17-3/4 450.8 3/4 19.05 26 11.8
CC5AXA042021 A 19-3/8 492.1 17-3/4 450.8 7/8 22.23 26 11.8
CC5AXW042024 A 22-15/16 582.6 16-3/16 411.1 7/8 22.23 28 12.7
CC5AXW048024 A 22-15/16 582.6 20-1/16 509.6 7/8 22.23 31 14.0
CC5AXC048021 A 19-3/8 492.1 20-1/16 509.6 7/8 22.23 27 12.2
CC5AXA060024 A 22-15/16 582.6 20-1/16 509.6 7/8 22.23 31 14.0
CC5AXW060031 A 29-15/16 760.4 20-1/16 509.6 7/8 22.23 39 17.7
C
10
13
/
16
″
(274.6)
3
/
16
″
(4.8)
19
″
(482.6)
1
3
/
4
″
(44.4)
3
3
/
16
″
(80.9)
2
15
/
16
″
(74.6)
A
2
5
/
16
″
(58.7)
13
/
16
″
(20.6)
9
1
/
2
″
(241.3)
7
1
/
4
″
(184.2)
1
7
/
16
″
(36.5)
11
/
16
″
(17.4)
1
7
/
16
″
(36.5)
D SUCTION LINE
3
/
8
″
LIQUID LINE
(9.5)
3
/
4
″
NPT PLUGGED
DRAIN
(19.1)
3
/
4
″
NPT DRAIN
(19.1)
FRONT RIGHT SIDE
19
″
(482.6)
1
3
/
8
″
(34.9)
3
3
/
16
″
(80.9)
2
15
/
16
″
(74.6)
D SUCTION LINE
3
/
8
″
LIQUID LINE
(9.5)
C
10
13
/
16
″
(274.6)
9
1
/
2
″
(241.3)
7
1
/
4
″
(184.2)
1
7
/
16
″
(36.5)
11
/
16
″
(17.4)
A
2
5
/
16
″
(58.7)
13
/
16
″
(20.6)
3
/
4
″
NPT DRAIN
(19.1)
1
7
/
16
″
(36.5)
LEFT SIDE FRONT
UNCASED COILS CC5AXA018, 024, 030, 036, 042, CC5AXW024, 030, 036 CC5AXCO48
UNCASED COILS CC5AXW042, 048, 060, CC5AXA060
