—25—
Table 16 — Fan Performance — 579F180 (High Heat Units)
LEGEND
NOTES:
1. Standard low-medium static drive range is 891 to 1179 rpm. Alternate high-
static drive range is 1227 to 1550. Other rpms require a field-supplied drive.
2. Maximum continuous bhp is 4.25 and the maximum continuous watts are
3775. Do not adjust motor rpm such that motor maximum bhp and/or watts is
exceeded at the maximum operating cfm.
3. Static pressure losses (i.e., EconoMi$erIV) must be added to external static
pressure before entering Fan Performance table.
4. Interpolation is permissible. Do not extrapolate.
5. Fan performance is based on wet coils, clean filters, and casing losses. See
Table 20 for accessory/FIOP static pressure information.
6. Extensive motor and drive testing on these units ensures that the full horse-
power and watts range of the motor can be utilized with confidence. Using
the fan motors up to the watts or bhp rating shown will not result in nuisance
tripping or premature motor failure. Unit warranty will not be affected.
7. Use of a field-supplied motor may affect wiring size. Contact the local Bryant
representative for details.
Table 17 — Fan Performance — 579F216 and 240 (High Heat Units)
LEGEND
NOTES:
1. Standard low-medium static drive range for size 216 is 910 to 1095 rpm.
Standard low-medium static drive range for size 240 is 1002 to 1225 rpm.
Alternate high-static drive range for size 216 is 1069 to 1287. Alternate high-
static drive range for size 240 is 1193 to 1458 rpm. Other rpms require a
field-supplied drive.
2. Maximum continuous bhp for size 216 is 5.90. Maximum continuous bhp for
size 240 is 8.7 (208/230 v) or 9.5 (460 v). The maximum continuous watts for
size 216 is 5180. The maximum continuous watts for size 240 is 7915
(208/230 v) or 8640 (460 v). Do not adjust motor rpm such that motor maxi-
mum bhp and/or watts is exceeded at the maximum operating cfm.
3. Static pressure losses (i.e., EconoMi$erIV) must be added to external static
pressure before entering Fan Performance table.
4. Interpolation is permissible. Do not extrapolate.
5. Fan performance is based on wet coils, clean filters, and casing losses. See
Table 21 for accessory/FIOP static pressure information.
6. Extensive motor and drive testing on these units ensures that the full horse-
power and watts range of the motor can be utilized with confidence. Using
the fan motors up to the watts or bhp rating shown will not result in nuisance
tripping or premature motor failure. Unit warranty will not be affected.
7. Use of a field-supplied motor may affect wiring size. Contact your local
Bryant representative for details.
AIRFLOW
(cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0 1.2
Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts
4500 819 1.55 1335 914 1.76 1518 1001 1.98 1705 1083 2.20 1894 1160 2.42 2088 1234 2.65 2284
4800 861 1.78 1538 951 2.00 1726 1035 2.22 1916 1113 2.45 2110 1188 2.68 2307 1259 2.91 2507
5100 904 2.04 1759 989 2.26 1952 1069 2.49 2147 1145 2.72 2345 1218 2.95 2545 1287 3.17 2749
5400 947 2.32 1999 1028 2.55 2197 1105 2.78 2396 1179 3.01 2598 1248 3.25 2802 1315 3.49 3009
5700 990 2.62 2259 1068 2.85 2461 1142 3.09 2665 1213 3.33 2871 1280 3.57 3079 1345 3.81 3289
6000 1034 2.94 2539 1109 3.18 2745 1180 3.42 2953 1248 3.67 3163 1313 3.91 3375 1376 4.16 3589
6300 1078 3.29 2840 1150 3.54 3050 1218 3.78 3262 1284 4.03 3476 1348 4.28 3692 — — —
6600 1123 3.67 3161 1192 3.91 3376 1258 4.16 3592 — — — — — — — — —
6900 1167 4.06 3504 1234 4.32 3723 — — — — — — — — — — — —
7200 —— — —— — —— ——— ——— ——— —
AIRFLOW
(cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.4 1.6 1.8 1.9 2.0
Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts
4500 1304 2.88 2484 1371 3.12 2688 1435 3.36 2895 1467 3.48 2999 1497 3.60 3104
4800 1327 3.14 2711 1393 3.38 2917 1456 3.62 3126 1486 3.75 3232 1517 3.87 3338
5100 1353 3.43 2955 1417 3.67 3165 1478 3.92 3377 1508 4.04 3484 1537 4.16 3592
5400 1380 3.73 3219 1442 3.98 3432 1502 4.23 3646 1531 4.35 3755 — — —
5700 14084.06350314684.313718—————————
6000 ———————————————
6300 ———————————————
6600 ———————————————
6900 ———————————————
7200 ———————————————
Bhp — Brake Horsepower
FIOP — Factory-Installed Option
Watts — Input Watts to Motor
AIRFLOW
(cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0 1.2
Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts
5,500 795 2.43 2043 866 2.74 2306 934 3.07 2578 998 3.40 2856 1059 3.74 3142 1117 4.08 3434
6,000 854 2.92 2452 921 3.24 2722 984 3.57 3998 1044 3.90 3281 1102 4.25 3570 1158 4.60 3865
6,500 914 3.46 2909 977 3.79 3184 1036 4.12 3465 1093 4.46 3752 1148 4.81 4045 1201 5.16 4343
7,000 975 4.06 3414 1034 4.39 3695 1090 4.73 3981 1144 5.08 4272 1196 5.43 4569 1246 5.79 4870
7,500 1037 4.72 3969 1092 5.06 4255 1145 5.41 4546 1196 5.76 4842 1256 6.12 5142 1294 6.48 5447
8,000 1099 5.44 4575 1150 5.79 4866 1201 6.14 5162 1249 6.50 5462 1297 6.86 5766 1343 7.22 6075
8,500 1161 6.22 5232 1210 6.57 5529 1258 6.93 5829 1304 7.29 6134 1349 7.66 6443 1393 8.03 6755
9,000 1223 7.07 5943 1270 7.43 6245 1315 7.79 6550 1360 8.16 6869 1403 8.53 7171 1445 8.90 7487
9,500 1286 7.98 6708 1331 8.34 7014 1374 8.71 7324 1416 9.08 7638 1457 9.46 7954 1498 9.84 8274
10,000 1349 8.95 7528 1392 9.32 7839 1433 9.70 8154 1473 10.07 8471 — — — — — —
AIRFLOW
(cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.4 1.6 1.8 1.9 2.0
Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts
5,500 1173 4.44 3732 1227 4.80 4036 1279 5.17 4345 1304 5.35 4502 1329 5.54 4629
6,000 1211 4.95 4165 1263 5.32 4471 1313 5.69 4782 1337 5.87 4939 1361 6.06 5097
6,500 1252 5.53 4646 1302 5.89 4954 1350 6.26 5267 1373 6.56 5425 1396 6.64 5584
7,000 1295 6.16 5176 1343 6.52 5487 1389 6.90 5802 1412 7.09 5961 1434 7.28 6121
7,500 1340 6.85 5756 1386 7.22 6070 1431 7.60 6387 1452 7.79 6547 1474 7.98 6709
8,000 1388 7.60 6388 1431 7.97 6704 1474 8.35 7024 1495 8.54 7186 1516 8.74 7348
8,500 1436 8.41 7071 1478 8.79 7390 1520 9.17 7713 1540 9.37 7876 — — —
9,000 14869.28780715279.678130—————————
9,500 153810.228597————————————
10,000 ———————————————
Bhp — Brake Horsepower
FIOP — Factory-Installed Option
Watts — Input Watts to Motor
