—26—
Table 18 — Fan Performance — 579F300 (High Heat Units)
LEGEND
NOTES:
1. Standard low-medium static drive range is 1066 to 1283 rpm. Alternate high-
static drive range is 1332 to 1550. Other rpms require a field-supplied drive.
2. Maximum continuous bhp is 10.2 (208/230 v) or 11.8 (460 v) and the maxi-
mum continuous watts are 9510 (208/230 v) or 11,000 (460 v). Do not adjust
motor rpm such that motor maximum bhp and/or watts is exceeded at the
maximum operating cfm.
3. Static pressure losses (i.e., EconoMi$erIV) must be added to external static
pressure before entering Fan Performance table.
4. Interpolation is permissible. Do not extrapolate.
5. Fan performance is based on wet coils, clean filters, and casing losses. See
Table 21 for accessory/FIOP static pressure information.
6. Extensive motor and drive testing on these units ensures that the full horse-
power and watts range of the motor can be utilized with confidence. Using
the fan motors up to the watts or bhp rating shown will not result in nuisance
tripping or premature motor failure. Unit warranty will not be affected.
7. Use of a field-supplied motor may affect wiring size. Contact your local
Bryant representative for details.
Table 19 — Air Quantity Limits
Table 20 — Accessory/FIOP Static Pressure*
(in. wg) — 579F180
LEGEND
FIOP — Factory-Installed Option
*The static pressure must be added to external static pressure. The
sum and the evaporator entering-air cfm should then be used in con-
junction with the Fan Performance tables to determine blower rpm and
watts.
Table 18 — Accessory/FIOP Static Pressure*
(in. wg) — 579F216-300
LEGEND
FIOP — Factory-Installed Option
*The static pressure must be added to external static pressure. The
sum and the evaporator entering-air cfm should then be used in con-
junction with the Fan Performance tables to determine blower rpm and
watts.
Table 22 — Perfect Humidity™ Dehumidification
Package Static Pressure Drop (in. wg)
AIRFLOW
(cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0 1.2
Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts
7,000 992 4.05 3,348 1051 4.44 3,668 1106 4.83 3995 1160 5.24 4331 1212 5.65 4675 1262 6.08 5026
7,500 1055 4.77 3,947 1110 5.17 4,277 1162 5.58 4615 1214 6.00 4960 1263 6.43 5312 1311 6.86 5672
8,000 1118 5.58 4,610 1170 5.99 4,950 1220 6.41 5298 1268 6.84 5653 1315 7.27 6014 1361 7.72 6382
8,500 1182 6.46 5,339 1231 6.88 5,690 1278 7.31 6047 1324 7.75 6411 1369 8.20 6782 1413 8.66 7158
9,000 1246 7.42 6,136 1292 7.86 6,498 1337 8.30 6865 1381 8.75 7239 1424 9.21 7618 1466 9.68 8003
9,500 1310 8.47 7,005 1354 8.92 7,377 1397 9.38 7754 1439 9.84 8137 1480 10.31 8525 1520 10.79 8918
10,000 1374 9.61 7,947 1416 10.07 8,329 1457 10.54 8715 1497 11.02 9107 1537 11.50 9504 — — —
10,500 1439 10.84 8,964 1479 11.32 9,356 1518 11.79 9752 — — — — — — — — —
11,000 1503 12.17 10,059 1542 12.65 10,460 — — — — — — — — — — — —
11,250 1536 12.86 10,636 — — — — — — — — — — — — — — —
AIRFLOW
(cfm)
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.4 1.6 1.8
Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts
7,000 1311 6.51 5385 1359 6.96 5751 1405 6.00 6124
7,500 1358 7.30 6039 1403 7.76 6412 1448 6.84 6792
8,000 1406 8.17 6767 1560 8.63 7137 1492 7.75 7524
8,500 1456 9.12 7541 1498 9.59 7929 1539 8.75 8323
9,000 1507 10.15 8393 1548 10.63 8790 — — —
9,500 —————————
10,000 —————————
10,500 —————————
11,000 —————————
11,250 —————————
Bhp — Brake Horsepower
FIOP — Factory-Installed Option
Watts — Input Watts to Motor
UNIT
579F
MINIMUM
COOLING
CFM
MINIMUM
HEATING CFM
MAXIMUM
CFM
Low Heat High Heat
180 4500 3800 3800 7,500
216 5400 4750 5450 9,000
240 6000 4750 5450 10,000
300 7000 4750 5450 11,250
COMPONENT
CFM
4500 5000 6000 7200 7500
EconoMi$erIV 0.04 0.05 0.07 0.09 0.10
COMPONENT
CFM
5000 6000 7200 9000 10,000 11,250
EconoMi$erIV 0.06 0.07 0.09 0.11 0.12 0.14
UNIT SIZE
579F
UNIT NOMINAL
TONS
CFM PER TON
300 400 500
180 15 .040 .071 .111
216 18 .058 .102 .160
240 20 .071 .126 .197
300 25 .111 .197 .308
