Table 23 — Fan Rpm at Motor Pulley Settings*
*Approximate fan rpm shown.
†Indicates standard low/medium static drive package.
**Indicates alternate high static-drive package.
††Due to belt and pulley size, pulley cannot be set to this number of
turns open.
NOTE: For speeds not listed above, field-supplied drives are required.
Table 24 — Evaporator-Fan Motor Data
LEGEND
*Extensive motor and electrical testing on these units ensures that the full horsepower (brake kilowatt) range
of the motors can be utilized with confidence. Using the fan motors up to the horsepower (brake kilowatt) rat-
ings shown in this table will not result in nuisance tripping or premature motor failure. Unit warranty will not
be affected.
NOTE: All indoor-fan motors 5 hp and larger meet the minimum efficiency requirements as established by the
Energy Policy Act of 1992 (EPACT) effective October 24, 1997.
Table 25 — Evaporator-Fan Motor Efficiency
NOTE: All indoor-fan motors 5 hp and larger meet the minimum effi-
ciency requirements as established by the Energy Policy Act of 1992
(EPACT) effective October 24, 1997.
UNIT 579F
MOTOR PULLEY TURNS OPEN
0
1/
2
11
1/
2
22
1/
2
33
1/
2
44
1/
2
55
1/
2
6
180† †† †† 1179 1150 1121 1093 1064 1035 1006 978 949 920 891
180** †† †† 1550 1522 1488 1455 1422 1389 1356 1323 1289 1256 1227
216† †† †† 1095 1077 1058 1040 1021 1002 984 965 947 928 910
216** †† †† 1287 1265 1243 1222 1200 1178 1156 1134 1112 1091 1069
240† †† †† 1225 1209 1187 1165 1143 1120 1098 1076 1053 1031 1002
240** †† †† 1458 1434 1407 1381 1354 1328 1301 1275 1248 1222 1193
300† †† †† 1283 1269 1247 1225 1203 1182 1160 1138 1116 1095 1066
300** †† †† †† †† 1551 1524 1497 1470 1443 1415 1388 1361 1332
UNIT
579F
UNIT
VOLTAGE
MAXIMUM ACCEPTABLE
CONTINUOUS BHP*
MAXIMUM ACCEPTABLE
CONTINUOUS BkW*
MAXIMUM ACCEPTABLE
OPERATING WATTS
MAXIMUM
AMP DRAW
180
208/230 4.25 3.17 3,775 10.5
460 4.25 3.17 3,775 4.8
216
208/230
5.90 4.40 5,180
15.8
460 7.9
240
208/230 8.70 6.49 7,915 22.0
460 9.50 7.08 8,640 13.0
300
208/230 10.20 7.61 9,510 28.0
460 11.80 8.80 11,000 14.6
BHP — Brake Horsepower
BkW — Brake Kilowatts
UNIT
579F
MOTOR EFFICIENCY
(%)
180 (3.7 Hp) 85.8
216 (5 Hp) 87.5
240 (7.5 Hp) 88.5
300 (10 Hp) 89.5
