Bryant ELECTRIC AIR CONDITIONER 561C - Unit Dimensions; Dimensions Table

—2—
DIMENSIONS—561C
A97017
AIR IN
NOTES:
1. Allow 30 in. clearance to service side of unit, 48 in. above unit, 6 in. on one side, 12 in.

on remaining side, and 24 in. between units for proper airflow. 2. Minimum outdoor operating ambient in cooling mode is 55°F, max. 125°F. 3. Series designation is the 14th position of the unit model number. 4. Center of gravity .
AIR IN
3
/8-IN. DIA
TIEDOWN
KNOCKOUTS
(2) PLACES
H
G
F
E
L
K
J
AIR IN
M
N
AIR DISCHARGE
AIR IN
AIR DISCHARGE
AIR DISCHARGE
A SQ
B
P
C
2
7
/8″
1
1
/4″
FIELD CONTROL SUPPLY  CONN
7
/
8
-IN. DIA HOLE
FIELD POWER SUPPLY CONN 7
/
8
-IN. DIA HOLE WITH 
1
1
/
8
-IN. DIA KNOCKOUT 
AND 1
3
/
8
-IN. DIA KNOCKOUT
3
/
8
-IN. DIA LIQUID 
LINE CONN
D DIA VAPOR LINE CONN
DIMENSIONS (IN.)
UNIT
SIZE SERIES
UNIT DIMENSIONS MINIMUM
MOUNTING
PAD DIMENSIONSABCDEFGHJKLMNP
018 A, D 18 21-15/16 3-3/16 5/8 3 15 16-5/16 17-3/4 10-3/16 16-1/8 17-3/4 7-7/8 8-3/8 9-3/8 18 X 18 024 A, D 18 23-15/16 3-3/16 5/8 3 15 16-5/16 17-3/4 10-3/16 16-1/8 17-3/4 7-7/8 8-3/8 9-1/2 18 X 18 030 A, D 22-1/2 21-15/16 3-3/16 3/4 3-11/16 18-1/8 19-3/4 22-1/4 14-3/8 19-9/16 22-1/16 10-3/8 10-1/4 10-3/4 22-1/2 X 22-1/2 036 A, B, D 22-1/2 25-15/16 3-3/16 3/4 3-11/16 18-1/8 19-3/4 22-1/4 14-3/8 19-9/16 22-1/16 10-1/4 9-1/2 11-1/4 22-1/2 X 22-1/2 036 E 22-1/2 25-15/16 3-3/16 3/4 3-11/16 18-1/8 19-3/4 22-1/4 14-3/8 19-9/16 22-1/16 10-3/8 10-3/4 11-1/4 22-1/2 X 22-1/2 042 A, C 22-1/2 29-15/16 3-1/4 7/8 3-11/16 18-1/8 19-13/16 22-1/4 14-3/8 19-9/16 22-1/16 10-1/4 9-1/2 11-5/8 22-1/2 X 22-1/2 042 B 22-1/2 29-15/16 3-1/4 7/8 3-11/16 18-1/8 19-13/16 22-1/4 14-3/8 19-9/16 22-1/16 10-3/8 10-3/4 11-1/8 22-1/2 X 22-1/2 048 A, B, C 30 27-15/16 3-1/4 7/8 6-1/2 23-1/2 27-1/4 29-3/4 20 27-1/16 29-9/16 15 13 14-1/2 30 X 30 060 A, E 30 35-15/16 3-1/4 7/8 6-1/2 23-1/2 27-1/4 29-3/4 20 27-1/16 29-9/16 15-1/2 14 15-1/2 30 X 30 060 B 30 29-15/16 3-1/4 7/8 6-1/2 23-1/2 27-1/4 29-3/4 20 27-1/16 29-9/16 15-1/2 14 15 30 X 30
