Bryant ELECTRIC AIR CONDITIONER 561C - Technical Specifications; Electrical and Compressor Details; Condenser Coil, Fan, and Optional Equipment

—4—
SPECIFICATIONS
See notes on page 7.
UNIT SIZE-SERIES 561C018-A, D 561C024-A, D 561C030-A, D 561C030-A
Operating Weight (Lb) 113/115 115/117 124/133 124
ELECTRICAL
Unit Volts—Hertz—Phase 208-230—60—1 208/230—60—3
Operating Voltage Range* 197—253 187—253
Compressor— Rated Load Amps 9.6/9.0 10.7/11.6 14.2/14.8 9.4
Locked Rotor Amps 49.0/48.0 56.0/60.0 75.0/73.0 68.0
Condenser Fan Motor—Full Load Amps 0.8 1.0 0.8 0.8
Min Unit Ampacity for Wire Sizing 12.8/12.1 14.4/15.5 18.6/19.3 12.6
Min Wire Size (60°C Copper) AWG† 14
Min Wire Size (75°C Copper) AWG† 14
Max Wire Length (60°C) (Ft)‡ 61/65 50/49 40 70
Max Wire Length (75°C) (Ft)‡ 58/61 50/47 40/38 65
Max Branch Circuit Fuse Size** 20/15 20 25 15
COMPRESSOR & REFRIGERANT
Compressor— Manufacturer Copeland/Bristol Copeland
Type Reciprocating
Temperature and Current Protection Internal Line Break
Refrigerant—Type and Amount @ 15 Ft R-22 and 3.25/3.30 R-22 and 3.76/3.65 R-22 and 4.19/4.25 R-22 and 4.19
CONDENSER COIL & FAN
Coil Face Area (Sq Ft) 5.6 6.2 7.4
Fins Per In.—Rows—Circuit
25—1—1/
22—1—1
25—1—1/
22—1—1
25—1—1/
25—1—1
25—1—2
Fan Motor—PSC Type, HP and RPM 1/8 and 1500 1/6 and 1500 1/10 and 1125 1/10 and 1125
Volts—Hertz—Phase 208/230—60—1
Condenser Airflow (CFM) 1400/1500 1550/1600 2000 1700
OPTIONAL EQUIPMENT
Coastal Filter KAACF0601SML KAACF0401MED
Time-Delay Relay KAATD0101TDR
Cycle Protector KSACY0101AAA
Low-Ambient Controller N/A P251-0083 (RCD)
Crankcase Heater KAACH1001AAA
Inlet Grille Kit KSABG0105CMC KSABG0205CMC KSABG0604CSM
Start Assist—Capacitor/Relay Type†† KSAHS0901AAA KSAHS1001AAA/KSAHS0901AAA/KSAHS0901AAA N/A
Start Assist—PTC Type KAACS0201PTC N/A
Sound Hood N/A
N/A / KSASH1301TEC/
KSASH2001BRL
N/A / KSASH1301TEC
TXV (RPB) KAATX0201RPB KAATX0301RPB KAATX0401RPB
TXV (Hard Shutoff)†† KSATX0601HSO
Low-Pressure Switch KAALP0101LPS
High-Pressure Switch KSAHI0101HPS
Filter Drier P502-8083S (RCD)
Evaporator Freeze Thermostat‡‡ KAAFT0101AAA
Liquid-Line Solenoid Valve†† KAALS0101LLS
Winter Start Control‡‡ KAAWS0101AAA
MotorMaster® Control*** N/A 32LT660004 (RCD)
Ball Bearing Fan Motor N/A HC34GE231 (RCD)
Thermostat, Auto Changeover,
Non-Programmable, °F/°C,
1-Stage Heat, 1-Stage Cool TSTATBBNAC01-B
Thermostat, Auto Changeover,
7-Day Programmable, °F/°C,
1-Stage Heat, 1-Stage Cool TSTATBBPAC01-B
Builder’s Thermostat, Manual Changeover,
Non-Programmable, °F/°C,
1-Stage Heat, 1-Stage Cool TSTATBBBAC01-B
Thermidistat Control, Programmable/
Non-Programmable Thermostat with
Humidity Control TSTATBBPRH01-B
Outdoor Air Temperature Sensor TSTATXXSEN01-B
Backplate for Non-Programmable
Thermostat TSTATXXNBP01
Backplate for Programmable Thermostat TSTATXXPBP01
Backplate for Builder’s Thermostat TSTATXXBBP01
Thermostat Conversion Kit (4 to 5 wire) TSTATXXCNV10
