DETAILED COOLING CAPACITIES#
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Total Sens‡ Total Sens‡ Total Sens‡ To tal Sens‡ To t al Sens‡ Total Sens‡
186BNA018****A Outdoor Section With CNPV*1917A**+TDR Indoor Section
525
57 (13.9) 21.63 10.95 1.12 20.61 10.57 1.26 19.54 10.18 1.41 18.41 9.76 1.58 17.21 9.34 1.77 15.94 8.89 1.97
62 (16.7) 19.55 13.28 1.12 18.63 12.90 1.26 17.65 12.51 1.41 16.62 12.09 1.57 15.53 11.66 1.75 14.37 11.21 1.96
63 (17.2)†† 18.05 12.76 1.12 17.20 12.38 1.26 16.30 11.98 1.40 15.33 11.57 1.56 14.31 11.14 1.75 13.23 10.68 1.96
67 (19.4) 17.71 15.58 1.12 16.88 15.21 1.25 16.01 14.81 1.40 15.10 14.39 1.56 14.22 14.22 1.75 13.36 13.36 1.96
72 (22.2) 17.06 17.06 1.12 16.42 16.42 1.25 15.73 15.73 1.40 14.99 14.99 1.56 14.20 14.20 1.75 13.33 13.33 1.96
600
57 (13.9) 22.11 11.53 1.14 21.03 11.14 1.29 19.90 10.74 1.44 18.72 10.32 1.61 17.48 9.88 1.79 16.16 9.43 2.00
62 (16.7) 19.99 14.19 1.14 19.02 13.81 1.28 18.00 13.40 1.43 16.92 12.98 1.60 15.79 12.54 1.78 14.58 12.08 1.99
63 (17.2)†† 18.48 13.61 1.14 17.58 13.22 1.28 16.63 12.82 1.43 15.63 12.39 1.59 14.56 11.95 1.78 13.44 11.49 1.98
67 (19.4) 18.18 16.82 1.14 17.33 16.42 1.28 16.46 16.46 1.43 15.67 15.67 1.59 14.81 14.81 1.78 13.88 13.88 1.99
72 (22.2) 17.88 17.88 1.14 17.18 17.18 1.28 16.44 16.44 1.43 15.64 15.64 1.59 14.79 14.79 1.78 13.86 13.86 1.99
675
57 (13.9) 22.46 12.08 1.17 21.34 11.68 1.32 20.17 11.27 1.47 18.95 10.85 1.64 17.66 10.41 1.82 16.31 9.95 2.03
62 (16.7) 20.34 15.07 1.17 19.32 14.67 1.31 18.26 14.26 1.46 17.15 13.83 1.63 15.98 13.38 1.81 14.75 12.91 2.02
63 (17.2)†† 18.80 14.42 1.17 17.86 14.03 1.31 16.88 13.62 1.46 15.84 13.18 1.62 14.75 12.73 1.80 13.60 12.25 2.01
67 (19.4) 18.61 18.52 1.17 17.85 17.85 1.31 17.05 17.05 1.46 16.21 16.21 1.62 15.30 15.30 1.80 14.32 14.32 2.01
72 (22.2) 18.57 18.57 1.17 17.82 17.82 1.31 17.03 17.03 1.46 16.18 16.18 1.62 15.27 15.27 1.80 14.30 14.30 2.01
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Total Sens‡ Total Sens‡ To tal Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
186BNA024****A Outdoor Section With CNPV*3117A**+TDR Indoor Section
700
57 (13.9) 28.62 14.37 1.54 27.23 13.51 1.73 25.76 12.66 1.94 24.22 11.82 2.16 22.61 10.99 2.41 20.92 10.17 2.69
62 (16.7) 26.01 17.59 1.54 24.72 16.64 1.73 23.39 15.71 1.93 21.99 14.77 2.15 20.51 13.85 2.40 18.97 12.93 2.68
63 (17.2)†† 24.07 16.91 1.55 22.89 15.98 1.73 21.64 15.06 1.92 20.33 14.14 2.14 18.96 13.23 2.39 17.51 12.32 2.67
67 (19.4) 23.66 20.76 1.55 22.51 19.72 1.73 21.32 18.69 1.92 20.11 20.07 2.14 18.99 18.99 2.39 17.81 17.81 2.67
72 (22.2) 23.01 23.01 1.55 22.09 22.09 1.73 21.11 21.11 1.92 20.07 20.07 2.14 18.96 18.96 2.39 17.78 17.78 2.67
800
57 (13.9) 29.14 15.12 1.58 27.70 14.25 1.77 26.17 13.37 1.98 24.57 12.50 2.20 22.90 11.64 2.45 21.16 10.79 2.73
62 (16.7) 26.54 18.82 1.58 25.20 17.83 1.77 23.80 16.84 1.97 22.34 15.87 2.19 20.81 14.90 2.43 19.21 13.94 2.72
63 (17.2)†† 24.59 18.05 1.58 23.34 17.08 1.76 22.05 16.12 1.96 20.69 15.16 2.18 19.26 14.21 2.43 17.77 13.26 2.71
67 (19.4) 24.26 22.42 1.58 23.11 23.01 1.76 22.04 22.04 1.96 20.92 20.92 2.18 19.73 19.73 2.43 18.47 18.47 2.71
72 (22.2) 24.05 24.05 1.58 23.05 23.05 1.76 22.00 22.00 1.96 20.89 20.89 2.18 19.71 19.71 2.43 18.45 18.45 2.71
900
57 (13.9) 29.51 15.85 1.62 28.04 14.95 1.81 26.46 14.05 2.02 24.81 13.15 2.24 23.10 12.27 2.49 21.31 11.39 2.77
62 (16.7) 26.93 20.00 1.62 25.54 18.97 1.80 24.10 17.94 2.01 22.60 16.92 2.23 21.03 15.91 2.47 19.40 14.90 2.75
63 (17.2)†† 24.97 19.15 1.62 23.69 18.14 1.80 22.35 17.14 2.00 20.95 16.14 2.22 19.49 15.15 2.47 17.97 14.15 2.75
67 (19.4) 24.96 24.96 1.62 23.89 23.89 1.80 22.77 22.77 2.00 21.59 21.59 2.22 20.34 20.34 2.47 19.00 19.00 2.75
72 (22.2) 24.92 24.92 1.62 23.86 23.86 1.80 22.74 22.74 2.00 21.56 21.56 2.22 20.31 20.31 2.47 18.98 18.98 2.75
See notes on pg. 15
