14
DETAILED COOLING CAPACITIES# CONTINUED
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Total Sens‡ Total Sens‡ To tal Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
186BNA042****A Outdoor Section With CNPV*4324A**+TDR Indoor Section
1225
57 (13.9) 49.34 24.70 2.66 47.47 24.08 3.01 45.41 23.40 3.42 43.15 22.67 3.88 40.71 21.89 4.39 38.06 21.06 4.98
62 (16.7) 44.95 30.44 2.64 43.25 29.86 2.99 41.39 29.23 3.38 39.33 28.54 3.84 37.11 27.79 4.36 34.71 26.99 4.94
63 (17.2)†† 41.76 29.29 2.63 40.20 28.71 2.97 38.47 28.07 3.36 36.56 27.37 3.82 34.50 26.62 4.33 32.25 25.80 4.91
67 (19.4) 41.12 36.11 2.63 39.63 35.56 2.97 38.01 34.93 3.36 36.38 36.38 3.82 34.75 34.75 4.33 32.94 32.94 4.92
72 (22.2) 40.25 40.25 2.62 39.10 39.10 2.96 37.79 37.79 3.36 36.33 36.33 3.82 34.70 34.70 4.33 32.90 32.90 4.92
1400
57 (13.9) 50.16 25.99 2.73 48.18 25.36 3.08 46.03 24.68 3.49 43.68 23.95 3.95 41.13 23.16 4.47 38.39 22.32 5.06
62 (16.7) 45.74 32.51 2.71 43.96 31.94 3.06 42.00 31.30 3.46 39.87 30.61 3.92 37.56 29.85 4.43 35.08 29.04 5.02
63 (17.2)†† 42.55 31.23 2.70 40.90 30.64 3.04 39.08 30.00 3.44 37.10 29.29 3.89 34.95 28.52 4.41 32.65 27.69 4.99
67 (19.4) 42.11 38.86 2.70 40.72 40.72 3.04 39.30 39.30 3.44 37.71 37.71 3.90 35.95 35.95 4.42 34.01 34.01 5.01
72 (22.2) 41.92 41.92 2.70 40.66 40.66 3.04 39.24 39.24 3.44 37.65 37.65 3.90 35.90 35.90 4.42 33.97 33.97 5.01
1575
57 (13.9) 50.74 27.21 2.80 48.70 26.58 3.16 46.46 25.90 3.56 44.03 25.16 4.03 41.41 24.38 4.55 38.60 23.54 5.14
62 (16.7) 46.32 34.50 2.78 44.48 33.92 3.13 42.46 33.29 3.53 40.26 32.59 3.99 37.89 31.82 4.51 35.38 30.98 5.10
63 (17.2)†† 43.12 33.07 2.77 41.42 32.49 3.11 39.54 31.84 3.51 37.50 31.12 3.97 35.30 30.34 4.48 32.96 29.47 5.07
67 (19.4) 43.35 43.35 2.77 42.00 42.00 3.11 40.47 40.47 3.52 38.78 38.78 3.98 36.91 36.91 4.50 34.86 34.86 5.09
72 (22.2) 43.29 43.29 2.77 41.94 41.94 3.11 40.42 40.42 3.52 38.73 38.73 3.98 36.87 36.87 4.50 34.82 34.82 5.09
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ To tal Sens‡ To t a l Sens‡
186BNA048****A Outdoor Section With CNPV*6124A**+TDR Indoor Section
1400
57 (13.9) 56.26 27.99 2.63 53.43 27.01 3.06 50.50 26.01 3.49 47.48 24.98 3.94 44.30 23.92 4.41 40.93 22.81 4.90
62 (16.7) 50.89 34.43 2.79 48.38 33.47 3.18 45.78 32.48 3.58 43.08 31.47 4.00 40.25 30.42 4.44 37.23 29.31 4.92
63 (17.2)†† 47.07 33.02 2.89 44.78 32.08 3.26 42.40 31.11 3.64 39.93 30.12 4.03 37.32 29.07 4.46 34.55 27.98 4.92
67 (19.4) 46.35 40.80 2.90 44.17 39.83 3.27 41.98 41.83 3.64 39.98 39.98 4.03 37.84 37.84 4.45 35.52 35.52 4.92
72 (22.2) 45.55 45.55 2.92 43.76 43.76 3.27 41.89 41.89 3.64 39.91 39.91 4.03 37.78 37.78 4.45 35.47 35.47 4.92
1600
57 (13.9) 57.28 29.51 2.66 54.30 28.50 3.10 51.24 27.48 3.54 48.08 26.43 4.00 44.78 25.35 4.47 41.29 24.22 4.97
62 (16.7) 51.86 36.85 2.83 49.21 35.85 3.23 46.50 34.85 3.64 43.69 33.81 4.06 40.75 32.72 4.51 37.65 31.58 4.99
63 (17.2)†† 47.99 35.27 2.94 45.57 34.29 3.31 43.10 33.30 3.70 40.52 32.28 4.10 37.82 31.20 4.53 34.97 30.07 5.00
67 (19.4) 47.61 47.41 2.94 45.63 45.63 3.31 43.61 43.61 3.69 41.47 41.47 4.09 39.16 39.16 4.52 36.67 36.67 5.00
72 (22.2) 47.50 47.50 2.94 45.56 45.56 3.31 43.54 43.54 3.69 41.41 41.41 4.09 39.11 39.11 4.52 36.63 36.63 5.00
1800
57 (13.9) 58.02 30.95 2.70 54.93 29.93 3.15 51.76 28.88 3.60 48.49 27.82 4.06 45.10 26.72 4.54 41.51 25.58 5.05
62 (16.7) 52.58 39.16 2.87 49.84 38.15 3.28 47.04 37.11 3.70 44.14 36.04 4.13 41.13 34.92 4.58 37.98 33.72 5.07
63 (17.2)†† 48.67 37.42 2.99 46.18 36.42 3.37 43.62 35.40 3.76 40.96 34.34 4.17 38.21 33.22 4.60 35.32 31.99 5.08
67 (19.4) 49.21 49.21 2.96 47.13 47.13 3.35 44.96 44.96 3.74 42.67 42.67 4.15 40.23 40.23 4.59 37.59 37.59 5.07
72 (22.2) 49.14 49.14 2.97 47.06 47.06 3.35 44.90 44.90 3.74 42.61 42.61 4.15 40.18 40.18 4.59 37.55 37.55 5.07
See notes on pg. 15
186B
